BOSCH REXROTH
9510290038
$682.57
USD
- BOSCH REXROTH
- Material:9510290038
- Model:AZPF-12-008LRR12MB GO2
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPF-12-008LRR12MB (9510290038) is an external gear pump designed for efficiency and reliability in converting mechanical energy into hydraulic energy. This model offers a counter-clockwise rotation and is equipped with a spline shaft adhering to SAE J T DP standards, ensuring compatibility with a wide range of equipment. The AZPF-12-008LRR12MB features a robust SAE J A bolt flange and thread UNB for secure line connections, complemented by an SAE O-ring for optimal sealing. With a geometric displacement of cm^3/rev, this pump is capable of achieving a maximum flow rate of . l/min, making it suitable for various applications requiring consistent hydraulic power. The unit's high precision manufacturing technology and pressure-dependent gap sealing contribute to its high efficiency and the prevention of excessive heat losses. Additionally, the use of slide bearings allows it to withstand high loads, extending the service life. Constructed from standard cast iron for the rear cover and corrosion-resistant aluminum for the housing material, the AZPF-12-008LRR12MB ensures durability in challenging environments. Its NBR sealing material is chosen for reliable performance, while the standard noise level operation makes it suitable for environments where noise reduction is beneficial. The pump's external gear unit function serves as a dependable source of hydraulic power across general applications. With its bearing diameter measuring mm and overall weight at . kg, this Bosch Rexroth gear pump balances compactness with robust functionality. It operates within a maximum intermittent pressure range and maintains consistent quality due to Bosch Rexroth's large-volume production capabilities.
The Bosch Rexroth AZPF-12-008LRR12MB (9510290038) is an external gear pump designed for efficiency and reliability in converting mechanical energy into hydraulic energy. This model offers a counter-clockwise rotation and is equipped with a spline shaft adhering to SAE J T DP standards, ensuring compatibility with a wide range of equipment. The AZPF-12-008LRR12MB features a robust SAE J A bolt flange and thread UNB for secure line connections, complemented by an SAE O-ring for optimal sealing. With a geometric displacement of cm^3/rev, this pump is capable of achieving a maximum flow rate of . l/min, making it suitable for various applications requiring consistent hydraulic power. The unit's high precision manufacturing technology and pressure-dependent gap sealing contribute to its high efficiency and the prevention of excessive heat losses. Additionally, the use of slide bearings allows it to withstand high loads, extending the service life. Constructed from standard cast iron for the rear cover and corrosion-resistant aluminum for the housing material, the AZPF-12-008LRR12MB ensures durability in challenging environments. Its NBR sealing material is chosen for reliable performance, while the standard noise level operation makes it suitable for environments where noise reduction is beneficial. The pump's external gear unit function serves as a dependable source of hydraulic power across general applications. With its bearing diameter measuring mm and overall weight at . kg, this Bosch Rexroth gear pump balances compactness with robust functionality. It operates within a maximum intermittent pressure range and maintains consistent quality due to Bosch Rexroth's large-volume production capabilities.
8 cm³/rev, Counter clockwise rotation, Spline shaft SAE J744 16-4 (9T 16/32DP) , SAE J744 82-2 (A) 2-bolt flange, Thread UN-2B, SAE O-ring
The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.
Unpacked Weight: 3.35 kg
| Consistent high quality based on large-volume production |
| Slide bearings for high loads |
| Port connections: flanged or threaded |
| Drive shafts according to ISO or SAE and customer specific solutions |
| Long service life |
| Offer Drawing | Download Offer Drawing |
| Data Sheet | Download Data Sheet |
| 3D CAD | Download 3D CAD |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Rear cover | Standard (cast iron) |
| Maximum rotational speed | 3000 |
| Productgroup ID | 7,21,22,23,24,25 |
| Size (geometric displacement) | 8 |
| Sealing material | NBR |
| Version | Corrosion resistant, pinned |
| Noise level | Standard noise level |
| External gear unit | External Gear Unit |
| Application | general |
| Drive shaft | Spline shaft SAE J744 16-4 (9T 16/32DP) |
| Housing material | Aluminum |
| Line connection | Thread UN-2B, SAE O-ring |
| Series | Model F (4 ... 28 cm³/rev) |
| Front cover | SAE J744 82-2 (A) 2-bolt flange |
| Maximum intermittent pressure | 210 |
| Direction of rotation | Counter clockwise rotation |
| Unit version | Bearing diameter 18mm |
| External gear unit function | Pump |
| Weight | 3.35 |
| Max. flow | 24.0 |
