BOSCH REXROTH
9510290124

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPF-12-022RQR12MB (9510290124) is a high-performance external gear pump designed for a wide range of applications requiring reliable hydraulic energy conversion. With a geometric displacement of 22 cm³/rev, this pump is capable of delivering a maximum flow rate of 22 l/min, ensuring efficient operation in demanding environments. It features clockwise rotation and a straight shaft SAE J744 short, complemented by an SAE J518 A bolt flange for secure and easy mounting. Constructed with a durable aluminum housing and standard cast iron rear cover, the AZPF-12-022RQR12MB pump is built to offer long service life and consistent high quality, supported by large-volume production standards. The unit employs slide bearings capable of handling high loads, contributing to the pump's robustness and reliability. The pump’s design incorporates pressure-dependent gap sealing and high-precision manufacturing technology to minimize heat losses and maximize efficiency. Its sealing material is NBR, which provides good resistance to oils and hydraulic fluids. The model also comes with corrosion-resistant features and a pinned version for added durability in harsh conditions. For versatile connection options, it includes port connections with thread UNF and SAE O-ring seals. The drive shaft conforms to ISO or SAE standards, with customer-specific solutions available upon request. This particular model boasts a standard noise level during operation, making it suitable for environments where noise reduction is beneficial. With its bearing diameter of 14 mm, the AZPF-12-022RQR12MB can endure an intermittent pressure maximum that ensures reliability during peak loads. Its unit version is designed to function effectively as an external gear unit pump, providing consistent performance throughout its lifespan while maintaining a weight of just 5.3 kg.
