BOSCH REXROTH
9510390002
$689.70 USD
- BOSCH REXROTH
- Material:9510390002
- Model:AZ-P-N-12-022-RDC12MB GO2
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPN-12-022RDC12MB (9510390002) is a high-performance external gear pump designed for efficient energy conversion from mechanical to hydraulic power. This unit is characterized by its clockwise rotation and features a spline shaft conforming to SAE J T DP standards, ensuring compatibility with a range of drive systems. The pump is equipped with an SAE J B bolt flange for secure mounting and utilizes UN thread and SAE O-ring ports for reliable fluid connections. Constructed with an aluminum housing, the AZPN-12-022RDC12MB ensures durability while maintaining a light weight of . kg. Its design incorporates slide bearings that can withstand high loads, contributing to the pump's long service life. The geometric displacement of this model is . cm³/rev, which facilitates a maximum flow rate of . l/min. This external gear pump by Bosch Rexroth boasts high precision manufacturing technology that includes pressure-dependent gap sealing for enhanced efficiency and reduced heat losses. It operates within standard noise levels, making it suitable for environments where noise reduction is beneficial. The unit's front cover integrates an SAE J B bolt flange, and the rear cover comes as standard. With its maximum intermittent pressure capability and standard NBR sealing material, the AZPN-12-022RDC12MB pump is also corrosion-resistant and pinned, further extending its serviceable life. With a housing width of mm, this external gear unit functions primarily as a pump within its product group. Its application is general in nature, but it excels particularly in systems requiring consistent high-quality performance based on large-volume production standards. The Bosch Rexroth AZPN-12-022RDC12MB external gear pump represents a reliable solution for diverse hydraulic energy needs.
The Bosch Rexroth AZPN-12-022RDC12MB (9510390002) is a high-performance external gear pump designed for efficient energy conversion from mechanical to hydraulic power. This unit is characterized by its clockwise rotation and features a spline shaft conforming to SAE J T DP standards, ensuring compatibility with a range of drive systems. The pump is equipped with an SAE J B bolt flange for secure mounting and utilizes UN thread and SAE O-ring ports for reliable fluid connections. Constructed with an aluminum housing, the AZPN-12-022RDC12MB ensures durability while maintaining a light weight of . kg. Its design incorporates slide bearings that can withstand high loads, contributing to the pump's long service life. The geometric displacement of this model is . cm³/rev, which facilitates a maximum flow rate of . l/min. This external gear pump by Bosch Rexroth boasts high precision manufacturing technology that includes pressure-dependent gap sealing for enhanced efficiency and reduced heat losses. It operates within standard noise levels, making it suitable for environments where noise reduction is beneficial. The unit's front cover integrates an SAE J B bolt flange, and the rear cover comes as standard. With its maximum intermittent pressure capability and standard NBR sealing material, the AZPN-12-022RDC12MB pump is also corrosion-resistant and pinned, further extending its serviceable life. With a housing width of mm, this external gear unit functions primarily as a pump within its product group. Its application is general in nature, but it excels particularly in systems requiring consistent high-quality performance based on large-volume production standards. The Bosch Rexroth AZPN-12-022RDC12MB external gear pump represents a reliable solution for diverse hydraulic energy needs.
22.5 cm³/rev, Clockwise rotation, Spline shaft SAE J744 22-4 (13T 16/32DP), SAE J744 101-2 (B) 2-bolt flange, Thread UN-2B, SAE O-ring
The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.
Unpacked Weight: 5.470 kg
| Consistent high quality based on large-volume production |
| Slide bearings for high loads |
| Port connections: flanged or threaded |
| Long service life |
| Drive shafts according to ISO or SAE and customer specific solutions |
| Offer Drawing | Download Offer Drawing |
| Data Sheet | Download Data Sheet |
| 3D CAD | Download 3D CAD |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Rear cover | Standard |
| Maximum rotational speed | 3000 |
| Productgroup ID | 7,21,22,23,24,25 |
| Size (geometric displacement) | 22.5 |
| Sealing material | NBR |
| Version | Corrosion resistant, pinned |
| Noise level | Standard noise level |
| External gear unit | External Gear Unit |
| Application | general |
| Drive shaft | Spline shaft SAE J744 22-4 (13T 16/32DP) |
| Housing material | Aluminum |
| Line connection | Thread UN-2B, SAE O-ring |
| Series | Model N (20 ... 36 cm³/rev) |
| Front cover | SAE J744 101-2 (B) 2-bolt flange |
| Maximum intermittent pressure | 210 |
| Direction of rotation | Clockwise rotation |
| Unit version | Housing width 110 mm |
| External gear unit function | Pump |
| Weight | 5.470 |
| Max. flow | 67.5 |
