BOSCH REXROTH
9510490049
$987.31 USD
- BOSCH REXROTH
- Material:9510490049
- Model:AZPG-22-056RDC40MB GO2
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPG-22-056RDC15MB (9510490049) is an external gear pump designed to efficiently convert mechanical energy into hydraulic energy, characterized by its high precision manufacturing and pressure-dependent gap sealing, which contribute to its high efficiency and reduced heat losses. This pump features a clockwise rotation and a spline shaft in accordance with SAE J T DP standards, ensuring compatibility with various drive systems. It is built to handle high loads with ease, thanks to its robust slide bearings and a durable aluminum housing. With its SAE J B bolt flange front cover and SAE Split flange line connections with UNC threads, the AZPG-22-056RDC15MB offers versatile port connection options. The unit's consistent quality is a result of Bosch Rexroth's large-volume production capabilities. It boasts a long service life due to its corrosion-resistant design with pinned components and standard sealing material NBR suitable for numerous applications. This model has a maximum rotational speed that ensures optimal performance for general external gear unit applications. The pump's geometric displacement is .056 cm³/rev, which allows for precise fluid control. It operates at standard noise levels, making it suitable for environments where noise reduction is beneficial. The maximum intermittent pressure it can withstand indicates its robustness in challenging operational conditions. The bearing diameter of 22 mm in the AZPG series Model G further exemplifies the pump’s capacity to support significant radial loads. With a weight of only .7 kg and a maximum flow rate of .9 l/min, this external gear unit combines lightweight construction with formidable hydraulic output, making it an essential component in various hydraulic systems where efficiency and reliability are paramount.
The Bosch Rexroth AZPG-22-056RDC15MB (9510490049) is an external gear pump designed to efficiently convert mechanical energy into hydraulic energy, characterized by its high precision manufacturing and pressure-dependent gap sealing, which contribute to its high efficiency and reduced heat losses. This pump features a clockwise rotation and a spline shaft in accordance with SAE J T DP standards, ensuring compatibility with various drive systems. It is built to handle high loads with ease, thanks to its robust slide bearings and a durable aluminum housing. With its SAE J B bolt flange front cover and SAE Split flange line connections with UNC threads, the AZPG-22-056RDC15MB offers versatile port connection options. The unit's consistent quality is a result of Bosch Rexroth's large-volume production capabilities. It boasts a long service life due to its corrosion-resistant design with pinned components and standard sealing material NBR suitable for numerous applications. This model has a maximum rotational speed that ensures optimal performance for general external gear unit applications. The pump's geometric displacement is .056 cm³/rev, which allows for precise fluid control. It operates at standard noise levels, making it suitable for environments where noise reduction is beneficial. The maximum intermittent pressure it can withstand indicates its robustness in challenging operational conditions. The bearing diameter of 22 mm in the AZPG series Model G further exemplifies the pump’s capacity to support significant radial loads. With a weight of only .7 kg and a maximum flow rate of .9 l/min, this external gear unit combines lightweight construction with formidable hydraulic output, making it an essential component in various hydraulic systems where efficiency and reliability are paramount.
56 cm³/rev, Clockwise rotation, Spline shaft SAE J744 22-4 (13T 16/32DP), SAE J744 101-2 (B) 2-bolt flange, SAE Split flange, UNC thread
The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.
Unpacked Weight: 8.000 kg
| Long service life |
| Slide bearings for high loads |
| Port connections: flanged or threaded |
| Consistent high quality based on large-volume production |
| Drive shafts according to ISO or SAE and customer specific solutions |
| Offer Drawing | Download Offer Drawing |
| Data Sheet | Download Data Sheet |
| 3D CAD | Download 3D CAD |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Rear cover | Standard |
| Maximum rotational speed | 2300 |
| Productgroup ID | 7,21,22,23,24,25 |
| Size (geometric displacement) | 56 |
| Sealing material | NBR |
| Version | Corrosion resistant, pinned |
| Noise level | Standard noise level |
| External gear unit | External Gear Unit |
| Application | general |
| Drive shaft | Spline shaft SAE J744 22-4 (13T 16/32DP) |
| Housing material | Aluminum |
| Line connection | SAE Split flange, UNC thread |
| Series | Model G (22.5 ... 56 cm³/rev) |
| Front cover | SAE J744 101-2 (B) 2-bolt flange |
| Maximum intermittent pressure | 230 |
| Direction of rotation | Clockwise rotation |
| Unit version | Bearing diameter 26 mm |
| External gear unit function | Pump |
| Weight | 8.000 |
| Max. flow | 128.8 |
