BOSCH REXROTH
9510490087

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPG-22-045RQC15MB (9510490087) is an external gear pump known for its capability to efficiently convert mechanical energy into hydraulic energy with minimal heat loss. This unit features a clockwise rotation and is designed with a straight keyed SAE J drive shaft and an SAE J524 B bolt flange front cover, ensuring compatibility with standard systems. The pump's high efficiencies are achieved through pressure-dependent gap sealing coupled with high-precision manufacturing technology. It boasts slide bearings capable of supporting high loads, contributing to the pump's robustness and long service life. With port connections that include an SAE split flange with UNC thread, this gear pump offers versatile connection options to suit various application needs. The housing material is made of corrosion-resistant aluminum, which contributes to the pump's durability and consistent performance in diverse operating conditions. The Bosch Rexroth AZPG-22-045RQC15MB has a geometric displacement size of 22 cm³/rev, which defines its capacity for fluid movement. This model comes standard with NBR sealing material and operates at a maximum rotational speed that supports its max flow rate of 45 l/min. It can handle a maximum intermittent pressure, ensuring reliable operation under varying pressure conditions. The bearing diameter stands at 45 mm, indicative of the unit's size and load-bearing capacity. Weighing in at approximately 10 kg, the Bosch Rexroth AZPG-22-045RQC15MB is designed for general application use where an external gear unit function is required. Its standard noise level makes it suitable for environments where noise reduction is beneficial but not critical. Overall, this external gear pump model combines quality manufacturing with functional design to deliver reliable hydraulic power for a wide range of applications.
