BOSCH REXROTH
R900049890

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth M-4SED6D1X/350CG96N9K4 (R900049890) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction. This direct-actuated seat valve comes with a concealed manual override and auxiliary actuation, ensuring versatility and ease of use in various applications. It is part of component series X, featuring the spool symbol D which indicates its specific flow path characteristics. With a maximum pressure capability and a connector pole PE electrical connection that complies with EN 175301-803 standards, this valve ensures safe and efficient operation. The product falls under Productgroup ID, which signifies its classification within Bosch Rexroth's product offerings. It boasts four ports for fluid transfer and utilizes solenoid actuation for precise control. The M-4SED6D1X/350CG96N9K4 valve conforms to CE standards and meets the Low Voltage Directive of the EU as well as CSA approval according to CSA C. No. 0-0-0-0. With a size designation that corresponds to CETOP D, it can be easily integrated into various hydraulic systems through subplate mounting. The connection diagrams are available in both NFPA T3.5.1 R2 D03 Size 3 and ISO patterns, ensuring compatibility with standard hydraulic setups. Designed to operate on a 24 VDC supply voltage, it features two switching positions that allow for flexible system integration. Weighing in at approximately .8 kg, this robust valve is suitable for use with a variety of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC types. The seals are made from NBR (nitrile rubber), providing reliable sealing performance under different operating conditions. Overall, the Bosch Rexroth M-4SED6D1X/350CG96N9K4 offers superior control for hydraulic systems requiring dependable directional flow switching capabilities with the added benefit of manual override options for enhanced operational flexibility.
