BOSCH REXROTH
R900057453
$48.52
- BOSCH REXROTH
- Material:R900057453
Quantity in stock: 932
Mating connector, connector 3-pole (2 + PE) EN 175301-803
For valves with connector K4. OEM accessories. Industrial use.
Unpacked Weight: 0.051 kg
| For valves with connector "K4" according to EN 175301-803 and ISO 4400, 2-pole + PE, "large cubic connector" |
| Mating connectors for valves with one or two solenoids (individual connection) |
| Data Sheet | Download Data Sheet |
| Manual | Download Manual |
| Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
| Productgroup ID | 9,10,11,12,13,14 |
| Electrical connector | Connector 3-pole (2 + PE) |
| Supply voltage | 12…240 V AC/DC |
| Weight | 0.051 |
For applications outside these parameters, please consult us!
|
Mating connector |
Short designation |
Z55L | ||
|
Design |
A | |||
|
Ambient temperature |
with indicator light/rectifier |
°C |
-20 … +60 | |
|
Protection class according to DIN EN 60529 |
IP65 with mating connector mounted and fitted | |||
|
Indicator light |
LED yellow | |||
|
Number of poles |
2 + PE | |||
|
Terminal area for lines with external diameter |
mm |
5 … 10 | ||
|
Wire cross-section, max. 1) |
mm² |
1.5 | ||
|
Anschlussart |
Screw connection | |||
|
Standard |
EN 175301-803 | |||
|
Derating, max. |
- | |||
| 1) | 2.5 mm2 with special wire end ferrule clamp (e. g. Knipex 975314 or Weidmüller PZ 6/5) |
With indicator light
Dimensions in mm
Dimensions in mm
|
1 |
Mounting screw M3 (not detachable), tightening torque MA = 0.5 Nm |
|
2 |
Fitting M16 x 1.5 / NPT 1/2“ (see table) |
