BOSCH REXROTH
R900224632

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth M-3SED6UK1X/350CG96N9K4/B12 (R900224632) is a high-performance industrial hydraulic valve designed to reliably switch oil flow direction in accordance with its hydraulic symbol. This direct-actuated seat valve features a throttle insert nozzle with a 0.00 mm channel in port P, ensuring precise control of fluid dynamics. The model is equipped with both concealed manual override and auxiliary actuation capabilities, enhancing its versatility and user control. This particular component belongs to series X and sports the spool symbol UK, indicating its specific function and design within the Bosch Rexroth valve lineup. It is capable of handling a maximum pressure with an electrical connection that utilizes a 4-pole PE connector conforming to EN 175301-803 standards. The product group identification numbers associated with this valve include several sequence numbers, which categorize the product within Bosch Rexroth's extensive catalog. Featuring four ports for comprehensive connectivity, the M-3SED6UK1X/350CG96N9K4/B12 valve is actuated by an electric solenoid, ensuring rapid response times and efficient operation. It adheres to CE conformity and meets the Low Voltage Directive of the EU as well as CSA approval according to CSA C22.2 No. 0 standards. With a size 6 interface for subplate mounting, this valve aligns with NFPA T3.5.1 R2 D03 and ISO 4401 size CETOP R35H standards for easy integration into various hydraulic systems. The supply voltage required is 24 VDC, catering to a wide range of industrial applications. The unit has two switching positions and weighs approximately .60 kg, making it robust yet manageable in terms of installation and maintenance. Its seals are made from NBR material suitable for use with various hydraulic fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC types. Overall, the Bosch Rexroth M-3SED6UK1X/350CG96N9K4/B12 offers reliable performance and adaptability for complex hydraulic systems requiring precise flow direction control.
