BOSCH REXROTH
R900999M11

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth HYDRAULIC CYLINDER CDM1 SERIE 3X KONFIG (R900999M11) is a robust and versatile hydraulic cylinder designed for demanding applications. This mill-type cylinder is engineered to operate at a nominal pressure of up to bar, with a piston diameter of mm, and a piston rod diameter of mm. It can accommodate stroke lengths up to mm, catering to a wide range of industrial requirements. Configurable online, the CDM1 series offers the convenience of automated provision of configuration-specific dimensional drawings and 3D data, ensuring precise integration into various systems. The installation dimensions are standardized according to ISO specifications, providing compatibility and ease of replacement or upgrade within existing frameworks. This hydraulic cylinder features several mounting options, accommodating different types of installations with self-adjusting and adjustable end position damping for enhanced performance. The patented safety vent allows for easy and safe bleeding during maintenance or setup processes. Assembly is made more efficient with the flexibility in positioning the line connections at both the cylinder head and base. This feature simplifies installation in complex machinery layouts where space constraints may exist. The maximum pressure rating indicates its ability to withstand heavy-duty operations while maintaining stability under static conditions. Its product group ID corresponds to a specific category within Bosch Rexroth's extensive product range, assuring users of its quality and compatibility with other components from the manufacturer. The CDM1 series hydraulic cylinder can work with various hydraulic fluids including HL, HLP, HFA, HFC, HFDR, and HFDU types. The seals are available in NBR or FKM materials to suit different operating environments and fluid types. With its robust construction and thoughtful design features like easy assembly and safety vents for bleeding, this hydraulic cylinder is well-suited for applications requiring reliable linear motion under high-pressure conditions.
