BOSCH REXROTH
R901344564

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 5-4WE10H5X/EG24N9K4/CM (R901344564) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction. This direct-actuated spool valve features the Spool symbol H, which indicates its function and design in hydraulic systems. It is capable of handling a maximum pressure with an electrical connection described by a Connector pole PE according to EN standards. The product belongs to the product group ID and is characterized by its number of ports and solenoid actuation type, signifying its capability for precise control in various applications. The size specification aligns with industry standards, ensuring compatibility with existing systems. The electrical connector also follows the Connector pole PE specification, providing secure and reliable connections. This Bosch Rexroth valve boasts a max flow rate that can be maintained through its subplate mounting connection type. The connection diagram adheres to both NFPA T3.5.1 R2 D03 and ISO 4401 standards, ensuring wide applicability and ease of integration into various hydraulic circuits. Operating on a supply voltage of 24 VDC and equipped with multiple switching positions, this valve allows for versatile operation within hydraulic systems. The weight is carefully calibrated to balance durability and ease of installation. Designed with NBR seals, it ensures compatibility with a range of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, HETG, and HFC types. This makes the Bosch Rexroth 5-4WE10H5X/EG24N9K4/CM valve suitable for varied industrial applications requiring precise fluid control under different operating conditions.
