BOSCH REXROTH
R901456971

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth 4WE6Y6X/EG24N9K4QMAG24/B10 (R901456971) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction. This direct-actuated spool valve features the spool symbol Y and is capable of handling a maximum pressure with exceptional precision. It is equipped with an electrical connection described as a connector pole PE according to EN, which ensures secure and stable connectivity for the solenoid actuation mechanism. The valve comes in size 6 and adheres to the CETOP D03 mounting pattern, making it compatible with standard interfaces for ease of integration into various hydraulic systems. The electrical connector is designed to accommodate a connector pole PE, further enhancing its robustness in demanding industrial environments. With its solenoid actuation, this Bosch Rexroth valve allows for precise control over the hydraulic fluid, supporting fluids such as HL, HLP, HLPD, HVLP, HVLPD, and HFC. The unit has a total number of four ports and provides two switching positions for versatile application in controlling flow direction. The 4WE6Y6X/EG24N9K4QMAG24/B10 operates on a supply voltage of 24 VDC and boasts a maximum flow capacity that ensures efficient performance in various hydraulic circuits. Its connection diagram follows both NFPA T3.5.1 R2 D03 and ISO standards for assured compatibility with existing systems. Weighing in at .kg, this valve is built to offer durability without adding significant weight to the system it serves. The NBR seals included are recognized for their resilience and compatibility with a range of hydraulic fluids, contributing to the valve's overall reliability and longevity in industrial applications.
