BOSCH REXROTH
R901480557

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth KUDSR3C2B/FN9V (R901480557) is a high-quality proportional flow control valve with an integrated pressure compensator designed for precise flow regulation in hydraulic systems. This screw-in cartridge valve has a maximum operating pressure of 315 bar (4568 psi) and can accommodate a maximum flow of 15 l/min (3.96 gpm), ensuring reliable performance in demanding applications. The valve's cavity is RUNF, which conforms to industry standards for ease of integration. The KUDSR3C2B/FN9V features electroproportional actuation, allowing for precise electronic control over the hydraulic fluid flow. It includes a concealed manual override for situations where electronic control is not feasible or in case of emergency. The sealing material used is FKM, known for its high resistance to heat and chemicals, which contributes to the valve's durability and longevity. This model falls under the product family classification of proportional flow control valves with integrated pressure compensators and belongs to the product family type KUDSR. It has a single port number configuration, and it operates normally closed when not energized. The nominal flow direction is direct, with a pilot-type direct acting mechanism that ensures responsive performance. The spool type within this valve is poppet, which provides excellent stability and repeatability in flow control operations. Weighing approximately 0.4 kg, the KUDSR3C2B/FN9V is suitable for various hydraulic fluids including HL, HLP, HEES, and HEPG types. As part of its configuration options, the coil required for operation must be ordered separately according to system requirements. This product represents Bosch Rexroth's commitment to precision engineering in hydraulic components and suits applications requiring meticulous flow management under varying pressure conditions.
