BOSCH REXROTH
R902502185
$2,606.37 USD
- BOSCH REXROTH
- Material:R902502185
- Model:AA10VSO28DFR/31R-VKC62K01
Quantity in stock: 2
The Bosch Rexroth A AA10VSO 28 DFR /31R-VKC62K01 (R902502185) is a high-performance, variable displacement unit designed specifically for hydrostatic drives in open circuit applications. This medium pressure pump features a size of 28 cm³ and is capable of operating with a nominal pressure of 280 bar and a maximum pressure of 350 bar, making it suitable for a wide range of demanding applications. The pump's flow varies in proportion to the drive speed and displacement, which can be seamlessly adjusted via the swash plate to meet precise requirements. Equipped with an SAE shaft key and mounting flange conforming to ISO and SAE standards, this model ensures compatibility with various systems. The DR F controller XT provides responsive control over the unit, while the FKM standard sealing material offers reliable sealing performance under various conditions. The pump operates with a clockwise rotation when viewed from the shaft end and has been designed without internal drain lines or connectors for solenoids to maintain simplicity. This axial piston unit from Bosch Rexroth boasts low operating noise and excellent suction characteristics, thanks to its optimized swashplate design. Its robust construction promises a long service life and short control response times, ensuring efficient operation throughout its lifespan. The through-drive feature allows for the mounting of additional pumps up to the same nominal size, enhancing system flexibility. The A AA10VSO 28 DFR /31R-VKC62K01 comes without paint on the topcoat or base coat and does not include a test certificate. It is available in the US version (SAE version), without any classification society external endorsements. This all-purpose medium pressure pump is designed for open circuit systems and excels in delivering consistent performance across various industrial applications.
A10VSO, variable displacement unit, open circuit, medium pressure, size: 28 cm³, pressure flow controller, with through drive
A10VSO is a variable pump with axial piston transmission in swash plate design for hydrostatic drives in the open circuit. The flow is proportional to the drive speed and the displacement. By adjusting the swash plate, the flow can be steplessly changed.
Unpacked Weight: 20 kg
Data Sheet | Download Data Sheet |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Paint/top coat | without |
Test certificate | Without |
Series | Series 3, index 1 |
Productgroup ID | 9,10,11,12,13,14 |
Rotational speed | 1800 |
Shaft end | SAE shaft key |
Control device | DR F controller X-T open 32/53 |
Sealing material | FKM (standard) |
Type of actuation | Variable pump, open circuit |
Working pressure | 280 |
Min. displacement setting | Fix |
Test certificate language code | Without |
Version_2 | US version |
Max. displacement setting | Fix |
Product family | A10VSO |
Classification society (external) | No |
Paint/base coat | without |
Max. flow | 50.4 |
Min. flow | 0.0 |
Direction of rotation | clockwise (w.view on shaft end) |
Connector for solenoids | Without |
Internal drain line | No |
Through drive | K 82-2; 5/8 in 9T 16/32DP |
Product (axial piston unit) | A10VS |
Version_1 | Standard |
Working ports | B flan l SAE, S flan l SAE |
Mounting flange | ISO 3019-1 (SAE), 2 hole |
Pressure differential FR | 14.0 |
Min. displacement | 0.0 |
Size (displacement) | 28 |
Max. displacement | 28.0 |
Weight | 20 |
Table of values
Size |
18 | 28 | 45 | 71 | 100 | 140 | 45 | 71 | 100 | 140 | |||
Version |
Standard | High speed | |||||||||||
Displacement |
Vg max |
cm³ |
18 | 28 | 45 | 71 | 100 | 140 | 45 | 71 | 100 | 140 | |
Nominal pressure |
pnom |
bar |
280 | 280 | 280 | 280 | 280 | 280 | 280 | 280 | 280 | 280 | |
Maximum pressure |
pmax |
bar |
350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | |
Maximum speed |
at Vg max |
nnom |
rpm |
3300 | 3000 | 2600 | 2200 | 2000 | 1800 | 3000 | 2550 | 2300 | 2050 |
Flow |
at Vg max and nnom |
qV nom |
l/min |
59 | 84 | 117 | 156 | 200 | 252 | 135 | 178 | 230 | 287 |
at Vg max and n = 1500 rpm |
qV 1500 |
l/min |
27 | 42 | 68 | 107 | 150 | 210 | |||||
Power |
at qV nom and pnom |
P |
kW |
30 | 39 | 55 | 73 | 93 | 118 | 63 | 83 | 107 | 134 |
at qV 1500 and pnom |
P 1500 |
kW |
12.6 | 20 | 32 | 50 | 70 | 98 | |||||
Torque |
at Vg max and pnom |
M |
Nm |
80 | 125 | 200 | 316 | 445 | 623 | 200 | 316 | 445 | 623 |
Weight (approx.) |
m |
kg |
12 | 15 | 21 | 33 | 45 | 60 | 21 | 33 | 45 | 60 |
