BOSCH REXROTH
R979107365
$203.13 USD
- BOSCH REXROTH
- Material:R979107365
- Model:AZPB-32-1.0RRR12KB
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth AZPB-32-1.0RRR12KB (R979107365) is an external gear pump designed for efficient conversion of mechanical energy into hydraulic energy, characterized by high precision manufacturing that ensures reduced heat losses and increased efficiency through pressure-dependent gap sealing. This pump features clockwise rotation and a spline shaft conforming to SAE J 744 AA standards, with a bolt flange also adhering to SAE J 744 AA specifications. The unit is capable of handling high loads thanks to its robust slide bearings and offers a long service life due to its consistent quality derived from large-volume production processes. Equipped with flanged or threaded port connections, the AZPB-32-1.0RRR12KB provides versatility for various piping configurations. Drive shaft options are available in accordance with ISO or SAE standards as well as customer-specific requirements. The rear cover is standard, while the maximum rotational speed is specified within the product group ID information. The geometric displacement size of this model is indicated by the manufacturer's specifications. Constructed from aluminum for the housing material, this gear pump ensures durability and corrosion resistance in demanding environments. The line connection utilizes a Thread UNB and an SAE O-Ring for secure and leak-proof operation. Belonging to Series Model B, this unit has a front cover featuring a bolt flange that complies with SAE J 744 AA standards. The maximum intermittent pressure capacity of the pump can be found in the technical documentation provided by Bosch Rexroth. Its bearing diameter stands at mm, signifying its capability to support external loads effectively. As for its function, it operates as a pump within an external gear unit system, maintaining a standard noise level during operation. Weighing in at . kg, this model boasts a maximum flow rate of . l/min, making it suitable for various hydraulic applications where reliable fluid transfer is essential. The sealing material used includes NBR for general sealing purposes and FKM for the shaft seal, enhancing its operational reliability under varying conditions. This specific version offers additional features such as corrosion resistance and pinned construction for enhanced performance and adaptability beyond standard catalogue offerings.
The Bosch Rexroth AZPB-32-1.0RRR12KB (R979107365) is an external gear pump designed for efficient conversion of mechanical energy into hydraulic energy, characterized by high precision manufacturing that ensures reduced heat losses and increased efficiency through pressure-dependent gap sealing. This pump features clockwise rotation and a spline shaft conforming to SAE J 744 AA standards, with a bolt flange also adhering to SAE J 744 AA specifications. The unit is capable of handling high loads thanks to its robust slide bearings and offers a long service life due to its consistent quality derived from large-volume production processes. Equipped with flanged or threaded port connections, the AZPB-32-1.0RRR12KB provides versatility for various piping configurations. Drive shaft options are available in accordance with ISO or SAE standards as well as customer-specific requirements. The rear cover is standard, while the maximum rotational speed is specified within the product group ID information. The geometric displacement size of this model is indicated by the manufacturer's specifications. Constructed from aluminum for the housing material, this gear pump ensures durability and corrosion resistance in demanding environments. The line connection utilizes a Thread UNB and an SAE O-Ring for secure and leak-proof operation. Belonging to Series Model B, this unit has a front cover featuring a bolt flange that complies with SAE J 744 AA standards. The maximum intermittent pressure capacity of the pump can be found in the technical documentation provided by Bosch Rexroth. Its bearing diameter stands at mm, signifying its capability to support external loads effectively. As for its function, it operates as a pump within an external gear unit system, maintaining a standard noise level during operation. Weighing in at . kg, this model boasts a maximum flow rate of . l/min, making it suitable for various hydraulic applications where reliable fluid transfer is essential. The sealing material used includes NBR for general sealing purposes and FKM for the shaft seal, enhancing its operational reliability under varying conditions. This specific version offers additional features such as corrosion resistance and pinned construction for enhanced performance and adaptability beyond standard catalogue offerings.
1 cm³/rev, Clockwise rotation, Spline shaft SAE J744 13-4 (A-A), 2-bolt flange SAE J744 50-2 (A-A), Thread UN-2B, SAE O-Ring
The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.
Unpacked Weight: 1.1 kg
Slide bearings for high loads |
Long service life |
Port connections: flanged or threaded |
Consistent high quality based on large-volume production |
Drive shafts according to ISO or SAE and customer specific solutions |
Offer Drawing | Download Offer Drawing |
Data Sheet | Download Data Sheet |
3D CAD | Download 3D CAD |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Rear cover | Standard |
Maximum rotational speed | 6000 |
Productgroup ID | 7,21,22,23,24,25 |
Size (geometric displacement) | 1 |
Sealing material | NBR, shaft seal in FKM |
Version | Corrosion resistant, pinned |
Special version | Deviations from catalogue standards, see drawing |
Noise level | Standard noise level |
External gear unit | External Gear Unit |
Application | general |
Drive shaft | Spline shaft SAE J744 13-4 (A-A) |
Housing material | Aluminum |
Line connection | Thread UN-2B, SAE O-Ring |
Series | Model B (0.84 ... 10 cm³/rev) |
Front cover | 2-bolt flange SAE J744 50-2 (A-A) |
Maximum intermittent pressure | 250 |
Direction of rotation | Clockwise rotation |
Unit version | Bearing diameter 12mm |
External gear unit function | Pump |
Weight | 1.1 |
Max. flow | 6.0 |
