HENGST
1013168B

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 10TDN0063-1X/PWR10A00-P2,2-M-R4 (1013168B) is a hydraulic-tank mounted filter designed for effective filtration of solids from liquids in hydraulic or lubrication systems. This duplex filter features a tank-mounted return line design, making it suitable for installation on liquid containers. It utilizes a multilayer glass fiber material, designated as PWR10, to ensure efficient filtration with a filtration grade of 10. The filter has a nominal size of 0063 and is equipped with an NBR seal, coded as M. Its housing is constructed from aluminum and plastic, providing durability while maintaining a lightweight structure. This model supports a maximum working pressure of 10 bar and features an optical indicator for monitoring purposes. The bypass cracking pressure is set at 3.5 bar, with a switching point at 2.2 bar to facilitate maintenance and operational efficiency. Designed with standard support cage material and adhering to the DIN24550 standard, the filter ensures reliable performance under demanding conditions. The Hengst filter also includes a port designation of G1 with horizontal positioning according to ISO228-1 standards, ensuring compatibility with various system configurations. Additionally, it incorporates an innovative ball valve change-over design that allows for seamless operation without interrupting the system flow during maintenance or changeovers. With its robust construction and advanced filtration capabilities, this tank-mounted return line filter is ideal for maintaining clean hydraulic fluids and extending the life of system components.
