HENGST
1013247B

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 10TEN0250-PWR20A00-V2,2-M-R6 (1013247B) is a hydraulic tank-mounted return line filter meticulously designed for the filtration of solids from liquids in hydraulic or lubrication systems. This single-unit filter, part of the 10TE series, is crafted with a multilayer glass fiber material known for its robust filtration capabilities. It features a nominal size of 0250 and utilizes an NBR seal designated by the code M. The filter is engineered to withstand a collapse pressure rating of up to 30 bar and operates effectively at a nominal pressure of 10 bar with a maximum working pressure also rated at 10 bar. The Hengst model incorporates an optical indicator for monitoring purposes, which activates at a switching point of 2.2 bar, ensuring timely maintenance and system reliability. Its tank-mounted design allows it to be installed on liquid containers with ease, while the housing material made from aluminum ensures durability and resistance to various environmental factors. The port configuration follows the ISO228-1 standard with a G1 1/2 designation and is positioned horizontally at the top of the tank. Additionally, this filter includes features such as suitability for HFC/HFA fluids and compliance with DIN24550 standards, enhancing its versatility across different applications. The support cage material is standard, providing adequate reinforcement to maintain structural integrity under operational conditions. With its advanced filtration grade of 20 and bypass cracking pressure set at 3.5 bar, this Hengst filter offers efficient performance in maintaining fluid cleanliness within hydraulic systems.
