HYDRAFORCE
5040002

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SV12-22-0-N-00 (5040002) is a solenoid-operated, 2-way, normally closed, poppet-type, screw-in hydraulic cartridge valve. It is primarily designed to function as a load holding or blocking valve in systems where low internal leakage is critical. The valve operates as a check valve when de-energized, allowing flow from port 1 to port 2 and preventing reverse flow. Upon energization, the poppet lifts to open the flow path between these ports, also permitting flow from port 2 to port 1. This model features a continuous-duty rated coil and a hardened seat that ensures long life and minimal leakage. It offers optional coil voltages and terminations for versatility in application. The wet-armature construction enhances its efficiency while the voltage-interchangeable cartridges add to its adaptability across different systems. The unitized, molded coil design contributes to its robustness and reliability in demanding environments. Additionally, the SV12-22-0-N-00 can be equipped with manual override options and optional waterproof E-Coils that are rated up to IP69K for high water resistance. Its efficient design is complemented by a cost-effective cavity that makes it an economical choice for various hydraulic applications. Key specifications include a pressure rating of up to 350 bar (5076 psi), operational fluid temperatures ranging from -40°C to +120°C (-40°F to +248°F) with Buna-N seals, and maximum internal leakage of just five drops per minute at maximum pressure. The valve fits into a VC10-3 cavity and can be used with size D or E coils according to system requirements. Seal kits and installation instructions are readily available for maintenance or replacement needs.
