HYDRAFORCE
5265840

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce PD12-S60N-0-N-110 (5265840) is a high-performance, screw-in, cartridge-style, pilot-operated, spool-type hydraulic directional valve designed for robust and efficient control in hydraulic systems. This valve facilitates precise flow direction between multiple ports: in its neutral position, it allows flow between ports 2 and 3 as well as between ports 4 and 5. Upon receiving a remote pilot signal at port 1, the spool shifts to connect ports 3 and 4 and ports 2 and 5 respectively. The design includes a vented spring chamber through port 6 which ensures that the valve can be fully pressurized at all operational ports without influencing the required pilot pressure, although pressure at port 6 does impact required pilot pressure. Constructed for durability and long service life, the PD12-S60N-0-N-110 features a hardened spool and cage. It operates effectively up to pressures of 344 bar (5000 psi) and is compatible with bias springs rated at both 110 psi and 170 psi. The valve's external surfaces are zinc-plated while work surfaces are made of hardened steel, ensuring resistance against wear and corrosion. Standard seals are made from Buna N with options for Viton or Polyurethane available through separate seal kits like SK12S6NBMMMM, SK12S6VBMMMM, or SK12S6PBMMMM. With an operating fluid temperature range from -40 to +120°C (-40 to +248°F), this valve maintains performance under varying environmental conditions. It also features maximum internal leakage of only 246 ml/min at a pressure of 207 bar (3000 psi). Weighing just about 0.45 kg (1 lb), it fits within standard size-12/6-way cavities, making installation versatile across different setups without requiring extensive modifications.
