SUN HYDRAULICS
CNBCXEV
$37.53 USD
- SUN HYDRAULICS
- Material:CNBCXEV
- Model:CNBC-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CNBCXEV (CNBCXEV) is a high-performance check valve designed for hydraulic applications requiring reliable, directional flow control. This model features a free-flow design from port 1 to port 2, facilitated by a customer-specified orifice that restricts flow in the reverse direction from port 2 to port 1. The specified orifice diameter can range between 0.016 to 0.062 inches (0.4 to 1.6 mm), tailored to specific application needs and is clearly stamped on one of the cartridge\u2019s hex faces for easy identification. Constructed to fit a T-16A cavity and part of the Series 0 line, the CNBCXEV supports a maximum operating pressure of up to 5000 psi (350 bar) and has a capacity of up to 7.5 gpm (30 L/min). This valve is notable for its robust build which incorporates Sun\u2019s floating style construction, minimizing potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. With a hex size of 3/4 inch (19.1 mm) and an installation torque requirement between 20 - 25 lbf\u00b7ft (27 - 33 Nm), this model ensures ease of installation while maintaining durability and performance integrity under high-pressure conditions. Weighing only about .20 lb (0.10 kg), it offers a compact yet powerful solution for hydraulic systems management. This check valve is also equipped with Viton seals, ensuring excellent resistance against high temperatures and chemical degradation, making it suitable for various demanding operational environments where precise fluid control is essential.
The Sun Hydraulics CNBCXEV (CNBCXEV) is a high-performance check valve designed for hydraulic applications requiring reliable, directional flow control. This model features a free-flow design from port 1 to port 2, facilitated by a customer-specified orifice that restricts flow in the reverse direction from port 2 to port 1. The specified orifice diameter can range between 0.016 to 0.062 inches (0.4 to 1.6 mm), tailored to specific application needs and is clearly stamped on one of the cartridge\u2019s hex faces for easy identification. Constructed to fit a T-16A cavity and part of the Series 0 line, the CNBCXEV supports a maximum operating pressure of up to 5000 psi (350 bar) and has a capacity of up to 7.5 gpm (30 L/min). This valve is notable for its robust build which incorporates Sun\u2019s floating style construction, minimizing potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. With a hex size of 3/4 inch (19.1 mm) and an installation torque requirement between 20 - 25 lbf\u00b7ft (27 - 33 Nm), this model ensures ease of installation while maintaining durability and performance integrity under high-pressure conditions. Weighing only about .20 lb (0.10 kg), it offers a compact yet powerful solution for hydraulic systems management. This check valve is also equipped with Viton seals, ensuring excellent resistance against high temperatures and chemical degradation, making it suitable for various demanding operational environments where precise fluid control is essential.
Free-flow, nose-to-side check valves with a bypass orifice allow free flow from port 1 to port 2. A customer specified orifice is included to restrict flow from port 2 to port 1. See technical data below for orifice range.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Valves with the opposite flow path (free flow from 2 to 1) are considered flow controls and may be found listed as fixed orifice, non-pressure compensated flow control valve with reverse flow check.
- The customer specified orifice diameter is stamped on one of the cartridge's hex faces.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-162A |
| Series | 0 |
| Capacity | 7.5 gpm30 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Orifice Range | .016 - .062 in.0,4 - 1,6 mm |
| Valve Hex Size | 3/4 in.19,1 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-162-006 |
