SUN HYDRAULICS
CNDEXZV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CNDEXZV (CNDEXZV) is a sophisticated pilot-to-close check cartridge valve designed for hydraulic systems requiring precise control of fluid flow. This valve is engineered to allow flow from port 1 to port 2 while restricting flow in the opposite direction, with an adjustable bypass orifice diameter that can be specified by the customer within an allowable range of 0.4 to 2.7 mm. The valve operates with a nominal pilot ratio of 1.8:1, meaning that pressure at the pilot port needs to be sufficiently high relative to the pressure at port 1 to keep the valve closed. The construction of the CNDEXZV incorporates hardened steel seats, enhancing its durability and ability to tolerate contamination. This makes it suitable for applications where wear and contamination are concerns. It also features Sun\u2019s floating style construction which reduces risks associated with internal parts binding due to installation torque or variations in cavity/cartridge machining. With a maximum operating pressure capacity of 5000 psi (350 bar) and a flow capacity up to 20 gpm (80 L/min), this valve is capable of handling substantial hydraulic loads. The design ensures that with equal pressures at all ports, the valve remains closed, providing reliable isolation until differential pressures dictate otherwise. Ideal for applications needing robust performance in challenging conditions, the CNDEXZV leverages its design features to provide effective and efficient hydraulic flow control in various industrial settings.
