SUN HYDRAULICS
CNFAXEN
$50.73 USD
- SUN HYDRAULICS
- Material:CNFAXEN
- Model:CNFA-XEN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CNFAXEN (CNFAXEN) is a high-performance hydraulic check valve designed for robust fluid control in various hydraulic systems. This valve allows free flow from port 1 to port 2, while a customer-specified orifice restricts flow in the reverse direction from port 2 to port 1, ensuring precise control over fluid movement. The CNFAXEN model is characterized by its compatibility with a T5A cavity and a Series 2 frame, supporting up to 30 gpm (120 L/min) capacity and withstanding maximum operating pressures of up to 5000 psi (350 bar). Key features of this model include an orifice range from .016 to .127 inches (0.4 to 3.2 mm), which can be specifically tailored to meet the needs of different applications. The valve's hex size is 1-1/8 inches (28.6 mm), and it requires an installation torque between 45 and 50 lbf\u00b7ft (61 - 68 Nm). Additionally, it incorporates Sun\u2019s floating style construction which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining\u2014enhancing reliability and performance longevity. The CNFAXEN is equipped with Viton seals (part number: 990203006), ensuring excellent resistance against high temperatures and chemical corrosion, making it suitable for challenging industrial environments. This model's design also facilitates easy maintenance and serviceability, further solidifying its utility in demanding operational conditions where precision and durability are paramount.
The Sun Hydraulics CNFAXEN (CNFAXEN) is a high-performance hydraulic check valve designed for robust fluid control in various hydraulic systems. This valve allows free flow from port 1 to port 2, while a customer-specified orifice restricts flow in the reverse direction from port 2 to port 1, ensuring precise control over fluid movement. The CNFAXEN model is characterized by its compatibility with a T5A cavity and a Series 2 frame, supporting up to 30 gpm (120 L/min) capacity and withstanding maximum operating pressures of up to 5000 psi (350 bar). Key features of this model include an orifice range from .016 to .127 inches (0.4 to 3.2 mm), which can be specifically tailored to meet the needs of different applications. The valve's hex size is 1-1/8 inches (28.6 mm), and it requires an installation torque between 45 and 50 lbf\u00b7ft (61 - 68 Nm). Additionally, it incorporates Sun\u2019s floating style construction which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining\u2014enhancing reliability and performance longevity. The CNFAXEN is equipped with Viton seals (part number: 990203006), ensuring excellent resistance against high temperatures and chemical corrosion, making it suitable for challenging industrial environments. This model's design also facilitates easy maintenance and serviceability, further solidifying its utility in demanding operational conditions where precision and durability are paramount.
Free-flow, nose-to-side check valves with a bypass orifice allow free flow from port 1 to port 2. A customer specified orifice is included to restrict flow from port 2 to port 1. See technical data below for orifice range.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Valves with the opposite flow path (free flow from 2 to 1) are considered flow controls and may be found listed as fixed orifice, non-pressure compensated flow control valve with reverse flow check.
- The customer specified orifice diameter is stamped on one of the cartridge's hex faces.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Orifice Range | .016 - .127 in.0,4 - 3,2 mm |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
