SUN HYDRAULICS
CNJCXEV
$180.09 USD
- SUN HYDRAULICS
- Material:CNJCXEV
- Model:CNJC-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CNJCXEV (CNJCXEV) is a two-port, free-flow check valve characterized by its unique design that supports a customer-specified orifice to regulate flow from port 2 to port 1, while allowing free flow from port 1 to port 2. This valve is designed for high-pressure applications, capable of handling up to 5000 psi or 350 bar at both ports. The CNJCXEV model is versatile in its application due to the customizable orifice range, which spans from 0.4 mm to 9 mm (.016 inches to .354 inches), allowing for precise control tailored to specific system requirements. The construction of the CNJCXEV utilizes Sun's floating style, which minimizes potential internal part binding that can result from excessive installation torque or variations in cavity/cartridge machining. This feature enhances the valve's reliability and durability in various operational conditions. The model also incorporates corrosion-resistant materials, making it suitable for use in environments where corrosion could be a concern. Additionally, the valve's design includes an installation torque range of 350 - 375 lbf ft (474 - 508 Nm) and accommodates a maximum flow capacity of up to 120 gpm (480 L/min). The cartridge's hex size is notably large at 1-5/8 inches (41.3 mm), and each valve's specific orifice diameter is conveniently stamped on one of the cartridge's hex faces for easy identification during maintenance or replacement processes. This check valve is ideal for hydraulic systems requiring robust performance with customizable flow control capabilities, ensuring efficient operation across a broad spectrum of industrial applications.
The Sun Hydraulics CNJCXEV (CNJCXEV) is a two-port, free-flow check valve characterized by its unique design that supports a customer-specified orifice to regulate flow from port 2 to port 1, while allowing free flow from port 1 to port 2. This valve is designed for high-pressure applications, capable of handling up to 5000 psi or 350 bar at both ports. The CNJCXEV model is versatile in its application due to the customizable orifice range, which spans from 0.4 mm to 9 mm (.016 inches to .354 inches), allowing for precise control tailored to specific system requirements. The construction of the CNJCXEV utilizes Sun's floating style, which minimizes potential internal part binding that can result from excessive installation torque or variations in cavity/cartridge machining. This feature enhances the valve's reliability and durability in various operational conditions. The model also incorporates corrosion-resistant materials, making it suitable for use in environments where corrosion could be a concern. Additionally, the valve's design includes an installation torque range of 350 - 375 lbf ft (474 - 508 Nm) and accommodates a maximum flow capacity of up to 120 gpm (480 L/min). The cartridge's hex size is notably large at 1-5/8 inches (41.3 mm), and each valve's specific orifice diameter is conveniently stamped on one of the cartridge's hex faces for easy identification during maintenance or replacement processes. This check valve is ideal for hydraulic systems requiring robust performance with customizable flow control capabilities, ensuring efficient operation across a broad spectrum of industrial applications.
Free-flow, nose-to-side check valves with a bypass orifice allow free flow from port 1 to port 2. A customer specified orifice is included to restrict flow from port 2 to port 1. See technical data below for orifice range.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Valves with the opposite flow path (free flow from 2 to 1) are considered flow controls and may be found listed as fixed orifice, non-pressure compensated flow control valve with reverse flow check.
- The customer specified orifice diameter is stamped on one of the cartridge's hex faces.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP or /LH (see CONFIGURATION section). For further details, please see the Materials of Construction page.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Orifice Range | .016 - .354 in.0,4 - 9 mm |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-018-006 |
