SUN HYDRAULICS
CNKCXAN
$313.43 USD
- SUN HYDRAULICS
- Material:CNKCXAN
- Model:CNKC-XAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CNKCXAN (CNKCXAN) is a sophisticated hydraulic check valve designed for versatile applications requiring reliable control of fluid flow. This model is engineered to allow free flow from port 1 to port 2, while incorporating a customer-specified orifice to restrict flow in the reverse direction, from port 2 to port 1. The specified orifice diameter enhances customization according to specific system requirements and is clearly stamped on one of the cartridge's hex faces for easy identification. Constructed with Sun's floating style design, the CNKCXAN minimizes potential internal binding caused by excessive installation torque or variances in cavity and cartridge machining. This feature ensures smooth operation and extends the durability of the valve under demanding conditions. The valve fits in a standard T18A cavity but achieves optimal performance when installed in a T18AU cavity, supporting up to 180 gpm (680 L/min) capacity and tolerating maximum operating pressures of 5000 psi (350 bar). The CNKCXAN valve is suitable for applications where precise fluid control is critical, thanks to its robust build and high capacity. Its versatility makes it ideal for integration into various hydraulic circuits that require dependable check valves with adjustable flow restrictions. The valve's technical specifications include an orifice range from .016 to .354 inches (0.4 to 9 mm), ensuring broad applicability across different hydraulic setups. Additionally, its construction allows for an installation torque between 350 - 375 lbf.ft (474 - 508 Nm), confirming its capability to withstand substantial mechanical forces during operation.
The Sun Hydraulics CNKCXAN (CNKCXAN) is a sophisticated hydraulic check valve designed for versatile applications requiring reliable control of fluid flow. This model is engineered to allow free flow from port 1 to port 2, while incorporating a customer-specified orifice to restrict flow in the reverse direction, from port 2 to port 1. The specified orifice diameter enhances customization according to specific system requirements and is clearly stamped on one of the cartridge's hex faces for easy identification. Constructed with Sun's floating style design, the CNKCXAN minimizes potential internal binding caused by excessive installation torque or variances in cavity and cartridge machining. This feature ensures smooth operation and extends the durability of the valve under demanding conditions. The valve fits in a standard T18A cavity but achieves optimal performance when installed in a T18AU cavity, supporting up to 180 gpm (680 L/min) capacity and tolerating maximum operating pressures of 5000 psi (350 bar). The CNKCXAN valve is suitable for applications where precise fluid control is critical, thanks to its robust build and high capacity. Its versatility makes it ideal for integration into various hydraulic circuits that require dependable check valves with adjustable flow restrictions. The valve's technical specifications include an orifice range from .016 to .354 inches (0.4 to 9 mm), ensuring broad applicability across different hydraulic setups. Additionally, its construction allows for an installation torque between 350 - 375 lbf.ft (474 - 508 Nm), confirming its capability to withstand substantial mechanical forces during operation.
Free-flow, nose-to-side check valves with a bypass orifice allow free flow from port 1 to port 2. A customer specified orifice is included to restrict flow from port 2 to port 1. See technical data below for orifice range.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Valves with the opposite flow path (free flow from 2 to 1) are considered flow controls and may be found listed as fixed orifice, non-pressure compensated flow control valve with reverse flow check.
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- The customer specified orifice diameter is stamped on one of the cartridge's hex faces.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 180 gpm680 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Orifice Range | .016 - .354 in.0,4 - 9 mm |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
