SUN HYDRAULICS
CNKCXBV
$319.88 USD
- SUN HYDRAULICS
- Material:CNKCXBV
- Model:CNKC-XBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CNKCXBV (CNKCXBV) is a precision-engineered hydraulic component designed for versatile fluid control applications. This model features a unique configuration with free flow from port 1 to port 2 and a customer-specified orifice that restricts flow in the reverse direction, from port 2 to port 1. The valve is tailored to operate within Sun's T18A cavity at reduced capacity, but for optimal performance reaching up to 180 gpm/680 L/min, the T18AU cavity is recommended. This check valve can withstand pressures up to 5000 psi (350 bar) at both ports, making it suitable for high-pressure systems. The specified orifice diameter, crucial for controlling flow rates, is conveniently stamped on one of the cartridge's hex faces for easy identification. This model also incorporates Sun's floating style construction which minimizes internal part binding and potential malfunctions due to installation torque or machining variations of the cavity/cartridge. Additionally, the CNKCXBV model has a robust design with a valve hex size of 1-5/8 in (41.3 mm) and requires an installation torque between 350 and 375 lbf\u00b7ft (474 - 508 Nm). Weighing in at approximately 2.10 lb (0.95 kg), this valve ensures reliability and durability across various hydraulic applications. Its compatibility with Viton seal kits further enhances its operational versatility and resilience under diverse conditions.
The Sun Hydraulics CNKCXBV (CNKCXBV) is a precision-engineered hydraulic component designed for versatile fluid control applications. This model features a unique configuration with free flow from port 1 to port 2 and a customer-specified orifice that restricts flow in the reverse direction, from port 2 to port 1. The valve is tailored to operate within Sun's T18A cavity at reduced capacity, but for optimal performance reaching up to 180 gpm/680 L/min, the T18AU cavity is recommended. This check valve can withstand pressures up to 5000 psi (350 bar) at both ports, making it suitable for high-pressure systems. The specified orifice diameter, crucial for controlling flow rates, is conveniently stamped on one of the cartridge's hex faces for easy identification. This model also incorporates Sun's floating style construction which minimizes internal part binding and potential malfunctions due to installation torque or machining variations of the cavity/cartridge. Additionally, the CNKCXBV model has a robust design with a valve hex size of 1-5/8 in (41.3 mm) and requires an installation torque between 350 and 375 lbf\u00b7ft (474 - 508 Nm). Weighing in at approximately 2.10 lb (0.95 kg), this valve ensures reliability and durability across various hydraulic applications. Its compatibility with Viton seal kits further enhances its operational versatility and resilience under diverse conditions.
Free-flow, nose-to-side check valves with a bypass orifice allow free flow from port 1 to port 2. A customer specified orifice is included to restrict flow from port 2 to port 1. See technical data below for orifice range.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Valves with the opposite flow path (free flow from 2 to 1) are considered flow controls and may be found listed as fixed orifice, non-pressure compensated flow control valve with reverse flow check.
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- The customer specified orifice diameter is stamped on one of the cartridge's hex faces.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 180 gpm680 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Orifice Range | .016 - .354 in.0,4 - 9 mm |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
