SUN HYDRAULICS
CNKCXCV
$317.90 USD
- SUN HYDRAULICS
- Material:CNKCXCV
- Model:CNKC-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CNKCXCV (CNKCXCV) is a versatile hydraulic check valve designed for high-pressure applications, accommodating up to 5000 psi (350 bar) at both ports. This model is specifically engineered to allow free flow from port 1 to port 2, while a customer-specified orifice restricts flow in the reverse direction, from port 2 to port 1. The orifice range for this valve spans from 0.016 inches to 0.354 inches (0.4 mm to 9 mm), allowing for precise control tailored to specific system requirements. Constructed for use in standard T18A cavities with reduced capacity, the CNKCXCV achieves its full performance capabilities when installed in a T18AU cavity. Notably, this model supports a substantial flow capacity of up to 180 gpm (680 L/min), making it suitable for a wide range of fluid dynamics applications. The valve's design incorporates Sun's floating style construction which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. Additional features include a hex size of 1-5/8 inches (41.3 mm) and an installation torque range of 350 - 375 lbf ft (474 - 508 Nm). Each valve weighs approximately 2.10 lbs (0.95 kg) and utilizes Viton seals for enhanced durability and performance under varying environmental conditions. The specific orifice diameter selected by the customer is conveniently stamped on one of the cartridge\u2019s hex faces, ensuring easy identification and maintenance.
The Sun Hydraulics CNKCXCV (CNKCXCV) is a versatile hydraulic check valve designed for high-pressure applications, accommodating up to 5000 psi (350 bar) at both ports. This model is specifically engineered to allow free flow from port 1 to port 2, while a customer-specified orifice restricts flow in the reverse direction, from port 2 to port 1. The orifice range for this valve spans from 0.016 inches to 0.354 inches (0.4 mm to 9 mm), allowing for precise control tailored to specific system requirements. Constructed for use in standard T18A cavities with reduced capacity, the CNKCXCV achieves its full performance capabilities when installed in a T18AU cavity. Notably, this model supports a substantial flow capacity of up to 180 gpm (680 L/min), making it suitable for a wide range of fluid dynamics applications. The valve's design incorporates Sun's floating style construction which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. Additional features include a hex size of 1-5/8 inches (41.3 mm) and an installation torque range of 350 - 375 lbf ft (474 - 508 Nm). Each valve weighs approximately 2.10 lbs (0.95 kg) and utilizes Viton seals for enhanced durability and performance under varying environmental conditions. The specific orifice diameter selected by the customer is conveniently stamped on one of the cartridge\u2019s hex faces, ensuring easy identification and maintenance.
Free-flow, nose-to-side check valves with a bypass orifice allow free flow from port 1 to port 2. A customer specified orifice is included to restrict flow from port 2 to port 1. See technical data below for orifice range.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Valves with the opposite flow path (free flow from 2 to 1) are considered flow controls and may be found listed as fixed orifice, non-pressure compensated flow control valve with reverse flow check.
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- The customer specified orifice diameter is stamped on one of the cartridge's hex faces.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 180 gpm680 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Orifice Range | .016 - .354 in.0,4 - 9 mm |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
