SUN HYDRAULICS
CNKCXZV
$321.87 USD
- SUN HYDRAULICS
- Material:CNKCXZV
- Model:CNKC-XZV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CNKCXZV (CNKCXZV) is a high-performance hydraulic check valve designed for efficient fluid control within hydraulic systems. This model features free flow from port 1 to port 2, while incorporating a customer-specified orifice to restrict flow in the reverse direction, from port 2 to port 1. The specific orifice diameter is clearly stamped on one of the cartridge's hex faces, offering customization based on client requirements within an orifice range of 0.016 to 0.354 inches (0.4 to 9 mm). Optimized for use in a T18AU cavity to achieve its full capacity of up to 180 gpm (680 L/min), the CNKCXZV can also operate in Sun\u2019s standard T18A cavity at a reduced capacity. It is engineered to withstand pressures up to 5000 psi (350 bar) at both ports, ensuring robust performance in demanding applications. The valve incorporates Sun Hydraulics\u2019 floating style construction which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. This model\u2019s versatility extends with its ability to be utilized as a flow control component when configured with an opposite flow path that allows free flow from port 2 to port 1. This dual functionality underscores its utility in various hydraulic circuit configurations, enhancing system efficiency and reliability. The CNKCXZV also maintains a compact form factor with a weight of approximately 2.10 lb (0.95 kg) and requires an installation torque between 350 and 375 lbf\u00b7ft (474 \u2013 508 Nm). With these attributes, the CNKCXZV stands out as a superior choice for specialized hydraulic applications requiring precise flow management and high-pressure tolerance.
The Sun Hydraulics CNKCXZV (CNKCXZV) is a high-performance hydraulic check valve designed for efficient fluid control within hydraulic systems. This model features free flow from port 1 to port 2, while incorporating a customer-specified orifice to restrict flow in the reverse direction, from port 2 to port 1. The specific orifice diameter is clearly stamped on one of the cartridge's hex faces, offering customization based on client requirements within an orifice range of 0.016 to 0.354 inches (0.4 to 9 mm). Optimized for use in a T18AU cavity to achieve its full capacity of up to 180 gpm (680 L/min), the CNKCXZV can also operate in Sun\u2019s standard T18A cavity at a reduced capacity. It is engineered to withstand pressures up to 5000 psi (350 bar) at both ports, ensuring robust performance in demanding applications. The valve incorporates Sun Hydraulics\u2019 floating style construction which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. This model\u2019s versatility extends with its ability to be utilized as a flow control component when configured with an opposite flow path that allows free flow from port 2 to port 1. This dual functionality underscores its utility in various hydraulic circuit configurations, enhancing system efficiency and reliability. The CNKCXZV also maintains a compact form factor with a weight of approximately 2.10 lb (0.95 kg) and requires an installation torque between 350 and 375 lbf\u00b7ft (474 \u2013 508 Nm). With these attributes, the CNKCXZV stands out as a superior choice for specialized hydraulic applications requiring precise flow management and high-pressure tolerance.
Free-flow, nose-to-side check valves with a bypass orifice allow free flow from port 1 to port 2. A customer specified orifice is included to restrict flow from port 2 to port 1. See technical data below for orifice range.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These valves will work in Sun's standard T-18A cavity at lower capacity. To realize the full stated capacity, the T-18AU cavity should be used.
- Valves with the opposite flow path (free flow from 2 to 1) are considered flow controls and may be found listed as fixed orifice, non-pressure compensated flow control valve with reverse flow check.
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- The customer specified orifice diameter is stamped on one of the cartridge's hex faces.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-18AU |
| Series | 4 |
| Capacity | 180 gpm680 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Orifice Range | .016 - .354 in.0,4 - 9 mm |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 2.10 lb0,95 kg |
| Seal kit - Cartridge | Viton: 990-018-006 |
