SUN HYDRAULICS
CODCXCN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CODCXCN (CODCXCN) is a highly efficient and reliable pilot-to-close check cartridge valve, designed to allow flow from port 1 to port 2 while blocking reverse flow under any condition. This valve features a nominal pilot ratio of 1.8:1, meaning it requires a pressure of 1000 psi at the pilot port to close against a pressure of 1800 psi at port 1. The unique construction of the CODCXCN incorporates Sun\u2019s floating style, which minimizes internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. The valve is specifically constructed to handle a maximum operating pressure of up to 5000 psi and has a flow capacity of up to 20 gpm (80 L/min). It is designed for T11A cavity series and offers minimal leakage, with maximum valve leakage defined at approximately one drop per minute. The installation specifications include a valve hex size of 7/8 inches and an installation torque range between 30-35 lbf ft. Weighing only about 0.30 lb, this model ensures durability and ease of handling during installation. Furthermore, the CODCXCN is equipped with Viton seals for enhanced performance under varying conditions, ensuring reliability and longevity in application. This model is ideal for hydraulic systems where precise flow control is necessary, and reverse flow prevention is critical, providing robust performance in demanding operational environments.
