SUN HYDRAULICS
CODLXFV
$76.94 USD
- SUN HYDRAULICS
- Material:CODLXFV
- Model:CODL-XFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CODLXFV (CODLXFV) is a highly reliable hydraulic valve designed for precise control in fluid power applications. This model, featuring a nominal pilot ratio of 1.8:1, allows for effective operation under varying pressure conditions. Specifically, a pilot pressure of 1000 psi at the pilot port can close the valve against a pressure of 1800 psi at port 1. The valve's design ensures that it remains closed with equal pressures at all ports and prevents reverse flow from port 2 to port 1 under any condition. Constructed with Sun's floating style, the CODLXFV minimizes potential internal parts binding which could result from excessive installation torque or variations in cavity/cartridge machining. This construction enhances the overall durability and reliability of the valve in demanding environments. It is engineered to fit a T11A cavity and belongs to the Series 1 category. Key specifications include a maximum operating pressure of 5000 psi and a flow capacity of up to 20 gpm (80 L/min). The valve maintains tight control over leakage, allowing no more than one drop per minute, ensuring efficient performance even under stringent conditions. For installation, it requires a hex size of 7/8 inches and an installation torque between 30 - 35 lbf ft. The model itself weighs approximately .30 lbs, making it lightweight yet robust for various hydraulic applications. Additionally, this model uses Viton seals (part number: 990011006), supporting its use in high-temperature environments where synthetic rubber provides superior performance over conventional rubbers. This combination of features makes the Sun Hydraulics CODLXFV an essential component for systems requiring precise fluid control with high reliability and minimal maintenance.
The Sun Hydraulics CODLXFV (CODLXFV) is a highly reliable hydraulic valve designed for precise control in fluid power applications. This model, featuring a nominal pilot ratio of 1.8:1, allows for effective operation under varying pressure conditions. Specifically, a pilot pressure of 1000 psi at the pilot port can close the valve against a pressure of 1800 psi at port 1. The valve's design ensures that it remains closed with equal pressures at all ports and prevents reverse flow from port 2 to port 1 under any condition. Constructed with Sun's floating style, the CODLXFV minimizes potential internal parts binding which could result from excessive installation torque or variations in cavity/cartridge machining. This construction enhances the overall durability and reliability of the valve in demanding environments. It is engineered to fit a T11A cavity and belongs to the Series 1 category. Key specifications include a maximum operating pressure of 5000 psi and a flow capacity of up to 20 gpm (80 L/min). The valve maintains tight control over leakage, allowing no more than one drop per minute, ensuring efficient performance even under stringent conditions. For installation, it requires a hex size of 7/8 inches and an installation torque between 30 - 35 lbf ft. The model itself weighs approximately .30 lbs, making it lightweight yet robust for various hydraulic applications. Additionally, this model uses Viton seals (part number: 990011006), supporting its use in high-temperature environments where synthetic rubber provides superior performance over conventional rubbers. This combination of features makes the Sun Hydraulics CODLXFV an essential component for systems requiring precise fluid control with high reliability and minimal maintenance.
The CODA has been upgraded so that there is no physical difference from the CODL.
- Nominal pilot ratio is 1.8:1. This means that a pressure of 1000 psi (70 bar) at the pilot port will close a valve against a pressure of 1800 psi (125 bar) at port 1. Any decay or loss of pilot pressure could allow the valve to open, even if it is a momentary decay or loss.
- Pressure at the port 2 area directly opposes pilot pressure.
- Reverse flow through the valve from port 2 to port 1 is not possible under any condition.
- With equal pressures at all ports the valve is closed.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 20 gpm80 L/min. |
| Pilot Ratio | 1.8:11.8:1 |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .30 lb0,15 kg |
| Seal kit - Cartridge | Viton: 990-011-006 |
