SUN HYDRAULICS
CSACEXV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CSACEXV (CSACEXV) is a high-performance shuttle valve designed for advanced hydraulic system applications. This model features a single ball shuttle that connects the higher of two work ports to the signal or common port, enhancing system efficiency and response. The external load port located in the hex end of the cartridge allows for easy access and handling, while the signal is conveniently sensed at port 2. Constructed with hardened steel balls and seats, the CSACEXV offers exceptional wear characteristics and contamination tolerance, ensuring durability and reliability in demanding environments. The valve's design incorporates Sun's floating style construction which minimizes internal parts binding that can occur due to excessive installation torque or variations in cavity/cartridge machining. Key specifications include a maximum operating pressure of 5000 psi (350 bar), a flow capacity of 2.5 gpm (10 L/min), and maximum valve leakage at 110 SUS (24 cSt) limited to 5 drops/min (0.3 cc/min). It fits within a T13A cavity, comes from Series 1, and requires an installation torque between 30-35 lbf ft (41-47 Nm). The model weighs approximately .20 lb (0.10 kg) and uses Viton seals for enhanced performance under various conditions. The CSACEXV is ideal for applications where precise control of fluid handling is necessary, such as in industrial machinery or mobile hydraulics systems where space and reliability are critical. Its robust design also makes it suitable for use in systems that experience varying pressures and flows, maintaining stability and performance throughout its operation.
