SUN HYDRAULICS
CSADBXV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CSADBXV (CSADBXV) is a high-performance single ball shuttle valve designed for hydraulic systems. This valve selectively connects the higher of two work ports to a signal or common port, with the pressure signal being sensed at port 2. The CSADBXV is notable for its robust construction, featuring hardened steel balls and seats that enhance wear characteristics and provide high tolerance against contamination. This makes it particularly suitable for applications where durability and reliability are critical. The valve's design allows the pressure signal to decay when both load ports experience a drop in pressure, ensuring stable system performance. It is configured with EPDM seals specifically for use with phosphate ester fluids, although it is crucial to avoid exposure to petroleum-based fluids, greases, and lubricants as they can damage the seals. Additionally, Sun Hydraulics has incorporated their floating style construction into this model, which helps minimize internal part binding that could result from excessive installation torque or variations in cavity/cartridge machining. With a flow capacity of 2.5 gpm (10 L/min) and a maximum operating pressure of 5000 psi (350 bar), the CSADBXV is well-suited for a wide range of hydraulic applications requiring precise fluid control. Its compact design includes a valve hex size of 7/8 in (22.2 mm) and an installation torque between 30 \u2013 35 lbf ft (41 \u2013 47 Nm). The model weighs approximately .20 lb (0.10 kg), facilitating easy integration into existing systems without significant adjustments to weight distribution or mounting configurations.
