SUN HYDRAULICS
CSADXXV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CSADXXV (CSADXXV) is a high-performance hydraulic shuttle valve designed for optimal fluid control in various applications. This model, equipped with a single ball shuttle, effectively connects the higher of two work ports to the signal or common port, where the pressure signal is sensed at port 2. The valve features a durable construction with hardened steel balls and seats, enhancing its wear characteristics and tolerance to contamination. It is specifically configured with EPDM seals suitable for systems using phosphate ester fluids, although these seals must avoid exposure to petroleum-based fluids which could cause damage. The CSADXXV operates efficiently within systems requiring a maximum of 2.5 gpm (10 L/min) flow capacity and can withstand pressures up to 5000 psi (350 bar). Its design incorporates Sun's floating style construction which minimizes internal parts binding\u2014a frequent issue arising from excessive installation torque or variations in cavity/cartridge machining. This model also boasts minimal valve leakage, quantified at about 5 drops/min (0.3 cc/min), ensuring precise fluid control and reduced wastage. With a compact and robust build, the valve has an installation torque range of 30-35 lbf ft (41-47 Nm) and weighs just 0.20 lb (0.10 kg), making it suitable for tight spaces and easy integration into existing systems without significant modifications. The CSADXXV uses a standard T11A cavity and is part of Sun Hydraulics' Series 1 line of valves, known for their reliability and performance in demanding hydraulic applications.
