SUN HYDRAULICS
CSAWEXV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CSAWEXV (CSAWEXV) is a highly efficient hydraulic shuttle valve designed for precision fluid control in various applications. This model features a single ball shuttle mechanism that effectively connects the higher of two work ports to a signal or common port, with the signal being sensed at an external port located in the hex end of the cartridge. This design allows for the decay of the pressure signal when both load ports drop to lower pressures, enhancing system responsiveness and stability. Constructed with hardened steel balls and seats, the CSAWEXV offers exceptional wear characteristics and contamination tolerance, making it suitable for environments where durability and reliability are paramount. The valve also incorporates Sun\u2019s floating style construction which minimizes internal parts binding, a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The CSAWEXV operates at a maximum pressure of 5000 psi (350 bar) and has a flow capacity of 1.25 gpm (4.7 L/min), ensuring robust performance in demanding applications. It also features low maximum valve leakage at 110 SUS (24 cSt), recorded at 5 drops/min (0.3 cc/min). The valve\u2019s hex size is 3/4 in (19.1 mm) and requires an installation torque between 20 - 25 lbf ft (27 - 33 Nm). Weighing only 0.20 lb (0.10 kg), this model is lightweight yet powerful, providing an optimal balance between efficiency and ease of integration into existing systems. Suitable seal kits for this cartridge are made from Viton, ensuring high compatibility and performance under varied operational conditions.
