SUN HYDRAULICS
CSAXBXV
$36.94 USD
- SUN HYDRAULICS
- Material:CSAXBXV
- Model:CSAX-BXV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CSAXBXV (CSAXBXV) is a high-performance shuttle valve designed for hydraulic systems requiring reliable load-sensing capabilities. This model features a single ball shuttle mechanism that effectively connects the higher of two work ports to the signal or common port, with the pressure signal sensed at port 3. The valve is engineered to allow pressure signal decay when both load ports experience a drop in pressure, enhancing system responsiveness and stability. Constructed with hardened steel balls and seats, the CSAXBXV exhibits superior wear characteristics and contamination tolerance, ensuring long-term durability and consistent performance even in demanding environments. The valve incorporates Sun\u2019s floating style construction which minimizes internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. This model is designed to fit a T-16A cavity and belongs to the Series 0. It has a flow capacity of 1.25 gpm (4.7 L/min) and can handle a maximum operating pressure of 5000 psi (350 bar). The maximum valve leakage is specified at 5 drops/min (0.3 cc/min), underlining its efficiency in maintaining system integrity. For installation, it requires a hex size of 3/4 in (19.1 mm) and an installation torque between 20 - 25 lbf\u00b7ft (27 - 33 Nm). The CSAXBXV weighs approximately 0.20 lb (0.10 kg), making it lightweight yet robust for various applications. Additionally, this model uses Viton seals for enhanced resistance against high temperatures and chemicals, further ensuring reliability in diverse operating conditions. The CSAXBXV is an essential component for hydraulic systems where precise fluid control and reliability are paramount.
The Sun Hydraulics CSAXBXV (CSAXBXV) is a high-performance shuttle valve designed for hydraulic systems requiring reliable load-sensing capabilities. This model features a single ball shuttle mechanism that effectively connects the higher of two work ports to the signal or common port, with the pressure signal sensed at port 3. The valve is engineered to allow pressure signal decay when both load ports experience a drop in pressure, enhancing system responsiveness and stability. Constructed with hardened steel balls and seats, the CSAXBXV exhibits superior wear characteristics and contamination tolerance, ensuring long-term durability and consistent performance even in demanding environments. The valve incorporates Sun\u2019s floating style construction which minimizes internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining. This model is designed to fit a T-16A cavity and belongs to the Series 0. It has a flow capacity of 1.25 gpm (4.7 L/min) and can handle a maximum operating pressure of 5000 psi (350 bar). The maximum valve leakage is specified at 5 drops/min (0.3 cc/min), underlining its efficiency in maintaining system integrity. For installation, it requires a hex size of 3/4 in (19.1 mm) and an installation torque between 20 - 25 lbf\u00b7ft (27 - 33 Nm). The CSAXBXV weighs approximately 0.20 lb (0.10 kg), making it lightweight yet robust for various applications. Additionally, this model uses Viton seals for enhanced resistance against high temperatures and chemicals, further ensuring reliability in diverse operating conditions. The CSAXBXV is an essential component for hydraulic systems where precise fluid control and reliability are paramount.
The single ball shuttle connects the higher of two work ports to the signal or common port. The signal is sensed at port 3.
- Shuttle cartridges feature hardened steel balls and seats for excellent wear characteristics and contamination tolerance.
- The single ball allows for the decay of the pressure signal when both load ports drop to a lower pressure.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-163A |
| Series | 0 |
| Capacity | 1.25 gpm4,7 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 5 drops/min.0,3 cc/min. |
| Valve Hex Size | 3/4 in.19,1 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-163-006 |
