SUN HYDRAULICS
CSAZAXN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CSAZAXN (CSAZAXN) is designed as a highly efficient hydraulic shuttle valve, ideal for systems where the highest of two work port pressures needs to be connected to a common or signal port, with the signal being sensed at port 2. This model is particularly noted for its robust construction featuring a single ball shuttle mechanism that ensures reliable performance by connecting only the higher pressure port, while allowing pressure decay when both load ports experience a drop in pressure. The hardened steel balls and seats within the valve enhance its wear characteristics and provide significant contamination tolerance. This valve incorporates Sun's floating style construction which minimizes potential internal parts binding that can occur due to excessive installation torque or variations in cavity/cartridge machining. It fits within a T163A cavity and belongs to the Series 0 category from Sun Hydraulics. The CSAZAXN has a flow capacity of 1.25 gpm (4.7 L/min) and can withstand a maximum operating pressure up to 5000 psi (350 bar). With maximum valve leakage specified at 5 drops/min (0.3 cc/min), it maintains efficiency even under stringent conditions. Key installation details include a valve hex size of 3/4 in. (19.1 mm) and an installation torque ranging between 20 - 25 lbf ft (27 - 33 Nm). The model's weight is minimal at approximately .20 lb (0.10 kg). For maintenance or repairs, it uses a Viton seal kit under part number: 990163006, ensuring long-term reliability and performance in various hydraulic applications.
