SUN HYDRAULICS
CSAZAXV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CSAZAXV (CSAZAXV) is a precision-engineered shuttle valve designed for hydraulic applications requiring the selection of the higher pressure between two input ports. This model effectively connects the higher of two work ports to a signal or common port, with the signal being sensed at port 2. It features a single ball shuttle mechanism, which allows for the decay of the pressure signal when both load ports drop to a lower pressure level. The valve is constructed with hardened steel balls and seats, enhancing its durability and contamination tolerance. The CSAZAXV incorporates Sun's floating style construction, which reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This model is housed within a T163A cavity and belongs to series 0. It has a capacity of up to 1.25 gpm (4.7 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). The valve exhibits minimal leakage, with a maximum rate of 5 drops/min at 110 SUS (24 cSt). For installation, it requires a hex size of 3/4 in (19.1 mm) and an installation torque between 20 - 25 lbf ft (27 - 33 Nm). The model weighs approximately 0.20 lb (0.10 kg), and utilizes Viton seals for enhanced performance under various conditions. This shuttle valve is ideal for applications where precise hydraulic flow management is critical, offering reliable performance even under challenging operational conditions.
