SUN HYDRAULICS
CXBAXBN
$27.80 USD
- SUN HYDRAULICS
- Material:CXBAXBN
- Model:CXBA-XBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXBAXBN (CXBAXBN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is characterized by its free-flow feature from inlet port 1 to outlet port 2, while effectively blocking flow in the reverse direction. Engineered for precision and durability, the CXBAXBN boasts an extremely low maximum leakage rate of less than 1 drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. Constructed with a robust floating style design, the CXBAXBN minimizes internal parts binding that can occur due to excessive installation torque or variations in cavity/cartridge machining. This feature aids in maintaining consistent performance and longevity of the valve under various installation conditions. The valve is suited for a maximum operating pressure of 5000 psi (350 bar) and has a flow capacity of up to 10 gpm (40 L/min). It is compatible with T-16A size cavities and can be installed using a standard 3/4 inch hex size tool. Particularly notable is the valve\u2019s compatibility with EPDM seals configured for use with phosphate ester fluids; however, it should not be exposed to petroleum-based fluids to avoid damage to the seals. The installation torque required ranges from 20 - 25 lbf ft (27 - 33 Nm), and the unit itself weighs approximately 0.20 lb (0.10 kg). For maintenance or repair, Viton seal kits are available under part number: 990162006. The Sun Hydraulics CXBAXBN check valve is an essential component for applications demanding reliable unidirectional flow control in hydraulic circuits, combining high-pressure capability with precision leakage control and durable construction.
The Sun Hydraulics CXBAXBN (CXBAXBN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is characterized by its free-flow feature from inlet port 1 to outlet port 2, while effectively blocking flow in the reverse direction. Engineered for precision and durability, the CXBAXBN boasts an extremely low maximum leakage rate of less than 1 drop per minute (0.07 cc/min), ensuring efficient operation and minimal fluid loss. Constructed with a robust floating style design, the CXBAXBN minimizes internal parts binding that can occur due to excessive installation torque or variations in cavity/cartridge machining. This feature aids in maintaining consistent performance and longevity of the valve under various installation conditions. The valve is suited for a maximum operating pressure of 5000 psi (350 bar) and has a flow capacity of up to 10 gpm (40 L/min). It is compatible with T-16A size cavities and can be installed using a standard 3/4 inch hex size tool. Particularly notable is the valve\u2019s compatibility with EPDM seals configured for use with phosphate ester fluids; however, it should not be exposed to petroleum-based fluids to avoid damage to the seals. The installation torque required ranges from 20 - 25 lbf ft (27 - 33 Nm), and the unit itself weighs approximately 0.20 lb (0.10 kg). For maintenance or repair, Viton seal kits are available under part number: 990162006. The Sun Hydraulics CXBAXBN check valve is an essential component for applications demanding reliable unidirectional flow control in hydraulic circuits, combining high-pressure capability with precision leakage control and durable construction.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-162A |
| Series | 0 |
| Capacity | 10 gpm40 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 3/4 in.19,1 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-162-006 |
