SUN HYDRAULICS
CXBAXCV
$32.27 USD
- SUN HYDRAULICS
- Material:CXBAXCV
- Model:CXBA-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXBAXCV (CXBAXCV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is crafted for seamless integration into various hydraulic circuits, ensuring free flow from inlet port 1 to outlet port 2 while blocking reverse flow to maintain system integrity. The CXBAXCV is distinguished by its capacity to handle up to 10 gpm (40 L/min) and withstand a maximum operating pressure of 5000 psi (350 bar), making it suitable for high-pressure applications. The valve features a T-16A cavity and utilizes Sun's floating style construction which helps prevent internal parts from binding due to over-torquing or machining variations in the cavity or cartridge. This design enhances the durability and reliability of the valve under varying operational conditions. The CXBAXCV has an exceptional low leakage rate, less than 1 drop per minute (0.07 cc/min), contributing to its efficiency and minimizing fluid loss in critical applications. For systems utilizing phosphate ester fluids, cartridges configured with EPDM seals are recommended; however, these should not be used with petroleum-based fluids as it can damage the seals. The valve's compact form factor, weighing just 0.20 lb (0.10 kg), along with a hex size of 3/4 in (19.1 mm) and an installation torque range of 20 - 25 lbf.ft (27 - 33 Nm), facilitates easy installation and maintenance without requiring extensive modifications to existing setups. This model is well-suited for various industrial applications where precise fluid control is crucial for system performance and safety.
The Sun Hydraulics CXBAXCV (CXBAXCV) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is crafted for seamless integration into various hydraulic circuits, ensuring free flow from inlet port 1 to outlet port 2 while blocking reverse flow to maintain system integrity. The CXBAXCV is distinguished by its capacity to handle up to 10 gpm (40 L/min) and withstand a maximum operating pressure of 5000 psi (350 bar), making it suitable for high-pressure applications. The valve features a T-16A cavity and utilizes Sun's floating style construction which helps prevent internal parts from binding due to over-torquing or machining variations in the cavity or cartridge. This design enhances the durability and reliability of the valve under varying operational conditions. The CXBAXCV has an exceptional low leakage rate, less than 1 drop per minute (0.07 cc/min), contributing to its efficiency and minimizing fluid loss in critical applications. For systems utilizing phosphate ester fluids, cartridges configured with EPDM seals are recommended; however, these should not be used with petroleum-based fluids as it can damage the seals. The valve's compact form factor, weighing just 0.20 lb (0.10 kg), along with a hex size of 3/4 in (19.1 mm) and an installation torque range of 20 - 25 lbf.ft (27 - 33 Nm), facilitates easy installation and maintenance without requiring extensive modifications to existing setups. This model is well-suited for various industrial applications where precise fluid control is crucial for system performance and safety.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-162A |
| Series | 0 |
| Capacity | 10 gpm40 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 3/4 in.19,1 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-162-006 |
