SUN HYDRAULICS
CXBAXDE
$127.88 USD
- SUN HYDRAULICS
- Material:CXBAXDE
- Model:CXBA-XDE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXBAXDE (CXBAXDE) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is part of Sun Hydraulics' extensive range of check valves and features a free-flow, nose-to-side configuration. It allows unobstructed flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring operational efficiency and safety in hydraulic circuits. The CXBAXDE model boasts an impressive maximum operating pressure of 5000 psi (350 bar) at both ports, accommodating demanding applications. It has a flow capacity of up to 10 gpm (40 L/min), making it suitable for a variety of industrial uses. The valve is engineered with Sun's floating style construction which helps prevent internal parts from binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. For systems using phosphate ester fluids, cartridges configured with EPDM seals are available; however, these are not compatible with petroleum-based fluids, greases, and lubricants as exposure can damage the seals. The valve's maximum leakage is exceptionally low, less than 1 drop per minute (0.07 cc/min), which contributes to its efficiency and reduces potential fluid loss. Physically, the CXBAXDE has a compact design with a weight of just 0.20 lbs (0.10 kg). Installation requires a hex size of 3/4 in. (19.1 mm) and a torque between 20 - 25 lbf.ft (27 - 33 Nm), facilitating easy integration into existing systems without requiring substantial modifications or complex setup procedures. This model uses Viton seals for enhanced performance under varying environmental conditions and chemical exposures.
The Sun Hydraulics CXBAXDE (CXBAXDE) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model is part of Sun Hydraulics' extensive range of check valves and features a free-flow, nose-to-side configuration. It allows unobstructed flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring operational efficiency and safety in hydraulic circuits. The CXBAXDE model boasts an impressive maximum operating pressure of 5000 psi (350 bar) at both ports, accommodating demanding applications. It has a flow capacity of up to 10 gpm (40 L/min), making it suitable for a variety of industrial uses. The valve is engineered with Sun's floating style construction which helps prevent internal parts from binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. For systems using phosphate ester fluids, cartridges configured with EPDM seals are available; however, these are not compatible with petroleum-based fluids, greases, and lubricants as exposure can damage the seals. The valve's maximum leakage is exceptionally low, less than 1 drop per minute (0.07 cc/min), which contributes to its efficiency and reduces potential fluid loss. Physically, the CXBAXDE has a compact design with a weight of just 0.20 lbs (0.10 kg). Installation requires a hex size of 3/4 in. (19.1 mm) and a torque between 20 - 25 lbf.ft (27 - 33 Nm), facilitating easy integration into existing systems without requiring substantial modifications or complex setup procedures. This model uses Viton seals for enhanced performance under varying environmental conditions and chemical exposures.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-162A |
| Series | 0 |
| Capacity | 10 gpm40 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 3/4 in.19,1 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-162-006 |
