SUN HYDRAULICS
CXBAXDV
$34.26 USD
- SUN HYDRAULICS
- Material:CXBAXDV
- Model:CXBA-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXBAXDV (CXBAXDV) is a high-performance, free-flow check valve designed for hydraulic systems. This valve allows free flow from the inlet port 1 to the outlet port 2 while blocking flow in the opposite direction, ensuring efficient operation in various hydraulic applications. The CXBAXDV is built to handle a maximum operating pressure of 5000 psi (350 bar) and has a flow capacity of up to 10 gpm (40 L/min). It features extremely low leakage rates, with a maximum of less than one drop per minute (0.07 cc/min), which contributes to its reliability and effectiveness in preventing fluid loss. The valve is housed in a T-16A cavity and incorporates Sun's floating style construction. This design minimizes potential internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining, enhancing its operational stability and longevity. The installation specifications include a valve hex size of 3/4 inch (19.1 mm) and an installation torque range of 20-25 lbf\u00b7ft (27-33 Nm). The model weighs approximately 0.20 lb (0.10 kg). For systems using phosphate ester fluids, cartridges configured with EPDM seals are recommended; however, these seals must not be exposed to petroleum-based fluids, greases, and lubricants as they can cause damage. The CXBAXDV model is ideal for applications requiring reliable one-way flow and minimal leakage in hydraulic circuits.
The Sun Hydraulics CXBAXDV (CXBAXDV) is a high-performance, free-flow check valve designed for hydraulic systems. This valve allows free flow from the inlet port 1 to the outlet port 2 while blocking flow in the opposite direction, ensuring efficient operation in various hydraulic applications. The CXBAXDV is built to handle a maximum operating pressure of 5000 psi (350 bar) and has a flow capacity of up to 10 gpm (40 L/min). It features extremely low leakage rates, with a maximum of less than one drop per minute (0.07 cc/min), which contributes to its reliability and effectiveness in preventing fluid loss. The valve is housed in a T-16A cavity and incorporates Sun's floating style construction. This design minimizes potential internal parts binding that could result from excessive installation torque or variations in cavity/cartridge machining, enhancing its operational stability and longevity. The installation specifications include a valve hex size of 3/4 inch (19.1 mm) and an installation torque range of 20-25 lbf\u00b7ft (27-33 Nm). The model weighs approximately 0.20 lb (0.10 kg). For systems using phosphate ester fluids, cartridges configured with EPDM seals are recommended; however, these seals must not be exposed to petroleum-based fluids, greases, and lubricants as they can cause damage. The CXBAXDV model is ideal for applications requiring reliable one-way flow and minimal leakage in hydraulic circuits.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-162A |
| Series | 0 |
| Capacity | 10 gpm40 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 3/4 in.19,1 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-162-006 |
