SUN HYDRAULICS
CXBAXEE
$125.89 USD
- SUN HYDRAULICS
- Material:CXBAXEE
- Model:CXBA-XEE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXBAXEE (CXBAXEE) is a precision-engineered check valve designed for hydraulic applications requiring reliable, one-way flow control. This model facilitates free flow from inlet port 1 to outlet port 2 while effectively blocking flow in the reverse direction, ensuring operational security and efficiency. The valve is compatible with a T-16A cavity and adheres to the Series 0 specifications. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity of up to 10 gpm (40 L/min), the CXBAXEE is suitable for high-pressure systems. It features an exceptionally low maximum leakage rate of less than one drop per minute (0.07 cc/min), which underscores its effectiveness in maintaining system integrity and minimizing fluid loss. The valve's dimensions include a hex size of 3/4 inch (19.1 mm) and it requires an installation torque between 20 - 25 lbf\u00b7ft (27 - 33 Nm). Weighing just 0.20 lb (0.10 kg), it is lightweight yet robust, designed to withstand challenging industrial conditions without compromising performance. Sun Hydraulics has incorporated their floating style construction into the CXBAXEE model, which reduces the risk of internal parts binding that can occur due to over-torquing or variances in cavity/cartridge machining. This design feature enhances the valve's reliability and longevity in diverse operational environments. Additionally, cartridges configured with EPDM seals are specifically intended for use with phosphate ester fluids, though they must not be exposed to petroleum-based fluids as these could damage the seals. Overall, the Sun Hydraulics CXBAXEE check valve offers superior performance in controlling fluid direction under high pressure, making it an essential component for sophisticated hydraulic systems demanding precise flow regulation and leak resistance.
The Sun Hydraulics CXBAXEE (CXBAXEE) is a precision-engineered check valve designed for hydraulic applications requiring reliable, one-way flow control. This model facilitates free flow from inlet port 1 to outlet port 2 while effectively blocking flow in the reverse direction, ensuring operational security and efficiency. The valve is compatible with a T-16A cavity and adheres to the Series 0 specifications. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity of up to 10 gpm (40 L/min), the CXBAXEE is suitable for high-pressure systems. It features an exceptionally low maximum leakage rate of less than one drop per minute (0.07 cc/min), which underscores its effectiveness in maintaining system integrity and minimizing fluid loss. The valve's dimensions include a hex size of 3/4 inch (19.1 mm) and it requires an installation torque between 20 - 25 lbf\u00b7ft (27 - 33 Nm). Weighing just 0.20 lb (0.10 kg), it is lightweight yet robust, designed to withstand challenging industrial conditions without compromising performance. Sun Hydraulics has incorporated their floating style construction into the CXBAXEE model, which reduces the risk of internal parts binding that can occur due to over-torquing or variances in cavity/cartridge machining. This design feature enhances the valve's reliability and longevity in diverse operational environments. Additionally, cartridges configured with EPDM seals are specifically intended for use with phosphate ester fluids, though they must not be exposed to petroleum-based fluids as these could damage the seals. Overall, the Sun Hydraulics CXBAXEE check valve offers superior performance in controlling fluid direction under high pressure, making it an essential component for sophisticated hydraulic systems demanding precise flow regulation and leak resistance.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Cartridges configured with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-162A |
| Series | 0 |
| Capacity | 10 gpm40 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 3/4 in.19,1 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-162-006 |
