SUN HYDRAULICS
CXBBBCV
$42.10 USD
- SUN HYDRAULICS
- Material:CXBBBCV
- Model:CXBB-BCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXBBBCV (CXBBBCV) is a high-performance check valve designed for hydraulic applications requiring reliable one-way flow and tight shut-off to prevent reverse flow. This model features a free flow from the inlet port 1 to the outlet port 2, with a maximum operating pressure of 5000 psi (350 bar) at both ports. The CXBBBCV is distinguished by its extremely low leakage rate, less than 1 drop per minute (0.07 cc/min), ensuring efficiency and minimal fluid loss in critical operations. Constructed with Sun's proprietary floating style, the CXBBBCV minimizes the risk of internal parts binding which can occur due to excessive installation torque or variations in cavity/cartridge machining. This design enhances the durability and reliability of the valve under varied operational conditions. The valve fits a T-16A cavity and has a flow capacity of up to 10 gpm (40 L/min), making it suitable for a wide range of medium-flow applications. Additionally, this model is engineered for easy installation with a hex size of 3/4 in (19.1 mm) and an installation torque requirement between 20 - 25 lbf\u00b7ft (27 - 33 Nm). Weighing just .20 lb (0.10 kg), the CXBBBCV provides a compact yet robust solution for hydraulic systems requiring dependable check valves. The valve also supports Viton seals through kit number 990162006, ensuring compatibility with various fluids and further enhancing its operational flexibility and resilience against different environmental conditions.
The Sun Hydraulics CXBBBCV (CXBBBCV) is a high-performance check valve designed for hydraulic applications requiring reliable one-way flow and tight shut-off to prevent reverse flow. This model features a free flow from the inlet port 1 to the outlet port 2, with a maximum operating pressure of 5000 psi (350 bar) at both ports. The CXBBBCV is distinguished by its extremely low leakage rate, less than 1 drop per minute (0.07 cc/min), ensuring efficiency and minimal fluid loss in critical operations. Constructed with Sun's proprietary floating style, the CXBBBCV minimizes the risk of internal parts binding which can occur due to excessive installation torque or variations in cavity/cartridge machining. This design enhances the durability and reliability of the valve under varied operational conditions. The valve fits a T-16A cavity and has a flow capacity of up to 10 gpm (40 L/min), making it suitable for a wide range of medium-flow applications. Additionally, this model is engineered for easy installation with a hex size of 3/4 in (19.1 mm) and an installation torque requirement between 20 - 25 lbf\u00b7ft (27 - 33 Nm). Weighing just .20 lb (0.10 kg), the CXBBBCV provides a compact yet robust solution for hydraulic systems requiring dependable check valves. The valve also supports Viton seals through kit number 990162006, ensuring compatibility with various fluids and further enhancing its operational flexibility and resilience against different environmental conditions.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-162A |
| Series | 0 |
| Capacity | 10 gpm40 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 3/4 in.19,1 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-162-006 |
