SUN HYDRAULICS
CXBGXBN
$21.94 USD
- SUN HYDRAULICS
- Material:CXBGXBN
- Model:CXBG-XBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXBGXBN (CXBGXBN) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow with minimal leakage. This valve allows free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring efficient operation in various hydraulic circuits. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity of up to 10 gpm (40 L/min), it meets demanding requirements for a wide range of applications. The CXBGXBN model features Sun Hydraulics' unique floating style construction which reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This design enhances durability and performance consistency. The valve's flush mount capability allows for a compact installation, minimizing space usage on the manifold. It is also characterized by its extremely low leakage rate, less than 1 drop per minute (0.07 cc/min), which is critical for maintaining system efficiency and preventing fluid loss. This model uses Viton seals for high temperature and chemical resistance, ensuring long service life even under harsh conditions. The valve is easy to install with an internal hex size of 5/16 in (8 mm) and requires an installation torque between 20 - 25 lbf\u00b7ft (27 - 33 Nm). Weighing just 0.20 lb (0.10 kg), the CXBGXBN provides a lightweight solution without compromising on strength or functionality, making it an ideal choice for integrated hydraulic systems looking for dependable check valve options.
The Sun Hydraulics CXBGXBN (CXBGXBN) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow with minimal leakage. This valve allows free flow from the inlet port 1 to the outlet port 2 while blocking flow in the reverse direction, ensuring efficient operation in various hydraulic circuits. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity of up to 10 gpm (40 L/min), it meets demanding requirements for a wide range of applications. The CXBGXBN model features Sun Hydraulics' unique floating style construction which reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. This design enhances durability and performance consistency. The valve's flush mount capability allows for a compact installation, minimizing space usage on the manifold. It is also characterized by its extremely low leakage rate, less than 1 drop per minute (0.07 cc/min), which is critical for maintaining system efficiency and preventing fluid loss. This model uses Viton seals for high temperature and chemical resistance, ensuring long service life even under harsh conditions. The valve is easy to install with an internal hex size of 5/16 in (8 mm) and requires an installation torque between 20 - 25 lbf\u00b7ft (27 - 33 Nm). Weighing just 0.20 lb (0.10 kg), the CXBGXBN provides a lightweight solution without compromising on strength or functionality, making it an ideal choice for integrated hydraulic systems looking for dependable check valve options.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Flush mount valves provide a small footprint. They can easily be mounted flush with the surface of the manifold.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-162A |
| Series | 0 |
| Capacity | 10 gpm40 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Internal Hex Size | 5/16 in.8 mm |
| Valve Installation Torque | 20 - 25 lbf ft27 - 33 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-162-006 |
