SUN HYDRAULICS
CXCDLCN
$33.76 USD
- SUN HYDRAULICS
- Material:CXCDLCN
- Model:CXCD-LCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXCDLCN (CXCDLCN) is a high-performance hydraulic check valve designed for efficient fluid control in various hydraulic systems. This model is part of the T13A series and features a two-port configuration, facilitating free flow from inlet port 2 to outlet port 1 while blocking flow in the reverse direction. The CXCDLCN valve is specifically engineered to address installation challenges, such as incorrect manifold drillings in existing circuits, making it an ideal solution for circuit correction without extensive modifications. The valve operates with a maximum capacity of 15 gallons per minute (60 L/min) and can withstand pressures up to 5000 psi (350 bar). It is built to minimize leakage, offering an exceptionally low maximum leakage rate of less than one drop per minute (0.07 cc/min). The construction incorporates Sun\u2019s floating style design which reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. With a compact model weight of just 0.20 lb (0.10 kg), the CXCDLCN ensures easy handling and installation, requiring an installation torque between 30 - 35 lbf ft (41 - 47 Nm). This valve uses Viton seals for enhanced durability and performance under varying conditions. Its robust design and precise engineering make it suitable for applications requiring reliable check valves that offer both high capacity and minimal leakage.
The Sun Hydraulics CXCDLCN (CXCDLCN) is a high-performance hydraulic check valve designed for efficient fluid control in various hydraulic systems. This model is part of the T13A series and features a two-port configuration, facilitating free flow from inlet port 2 to outlet port 1 while blocking flow in the reverse direction. The CXCDLCN valve is specifically engineered to address installation challenges, such as incorrect manifold drillings in existing circuits, making it an ideal solution for circuit correction without extensive modifications. The valve operates with a maximum capacity of 15 gallons per minute (60 L/min) and can withstand pressures up to 5000 psi (350 bar). It is built to minimize leakage, offering an exceptionally low maximum leakage rate of less than one drop per minute (0.07 cc/min). The construction incorporates Sun\u2019s floating style design which reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. With a compact model weight of just 0.20 lb (0.10 kg), the CXCDLCN ensures easy handling and installation, requiring an installation torque between 30 - 35 lbf ft (41 - 47 Nm). This valve uses Viton seals for enhanced durability and performance under varying conditions. Its robust design and precise engineering make it suitable for applications requiring reliable check valves that offer both high capacity and minimal leakage.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-13A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-010-006 |
