SUN HYDRAULICS
CXCDLZV
$44.18 USD
- SUN HYDRAULICS
- Material:CXCDLZV
- Model:CXCD-LZV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXCDLZV (CXCDLZV) is a high-performance check valve specifically designed for hydraulic applications requiring reliable one-way flow and minimal leakage. This model features a sidetonose check configuration that facilitates free flow from the inlet port 2 to the outlet port 1, while effectively blocking flow in the reverse direction. The CXCDLZV is particularly beneficial in circuits where manifold drillings are incorrect, acting as a circuit saver by accommodating these variations without the need for extensive redesign or replacement. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity of 15 gpm (60 L/min), this valve meets rigorous demands for both industrial and mobile applications. It boasts an exceptionally low leakage rate of less than 1 drop per minute (0.07 cc/min), ensuring efficient operation and reducing system losses. The valve's construction incorporates Sun's floating style design which minimizes risks of internal parts binding due to over-torquing or machining discrepancies during installation. This model is housed in a T13A cavity and follows Series 1 specifications. It supports a valve hex size of 7/8 inches (22.2 mm) and requires an installation torque between 30 \u2013 35 lbf-ft (41 \u2013 47 Nm). Weighing just 0.20 lb (0.10 kg), the CXCDLZV is lightweight yet robust, suitable for various hydraulic systems where space and weight are critical factors. Additionally, it utilizes Viton seals for enhanced durability and chemical resistance, making it a versatile choice across diverse operating environments.
The Sun Hydraulics CXCDLZV (CXCDLZV) is a high-performance check valve specifically designed for hydraulic applications requiring reliable one-way flow and minimal leakage. This model features a sidetonose check configuration that facilitates free flow from the inlet port 2 to the outlet port 1, while effectively blocking flow in the reverse direction. The CXCDLZV is particularly beneficial in circuits where manifold drillings are incorrect, acting as a circuit saver by accommodating these variations without the need for extensive redesign or replacement. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity of 15 gpm (60 L/min), this valve meets rigorous demands for both industrial and mobile applications. It boasts an exceptionally low leakage rate of less than 1 drop per minute (0.07 cc/min), ensuring efficient operation and reducing system losses. The valve's construction incorporates Sun's floating style design which minimizes risks of internal parts binding due to over-torquing or machining discrepancies during installation. This model is housed in a T13A cavity and follows Series 1 specifications. It supports a valve hex size of 7/8 inches (22.2 mm) and requires an installation torque between 30 \u2013 35 lbf-ft (41 \u2013 47 Nm). Weighing just 0.20 lb (0.10 kg), the CXCDLZV is lightweight yet robust, suitable for various hydraulic systems where space and weight are critical factors. Additionally, it utilizes Viton seals for enhanced durability and chemical resistance, making it a versatile choice across diverse operating environments.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-13A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-010-006 |
