SUN HYDRAULICS
CXCDXDV
$34.26 USD
- SUN HYDRAULICS
- Material:CXCDXDV
- Model:CXCD-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXCDXDV (CXCDXDV) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This valve facilitates free flow from inlet port 2 to outlet port 1 while blocking the reverse flow, making it an essential component for circuits needing precise fluid control. The CXCDXDV model is housed in a T13A cavity and belongs to the Series 1 category of Sun Hydraulics' products. With a capacity of 15 gallons per minute (60 liters per minute) and the ability to withstand a maximum operating pressure of 5000 psi (350 bar), this valve is crafted to handle demanding applications. It features exceptionally low leakage rates, with maximum leakage confined to less than one drop per minute (0.07 cc/min), ensuring efficiency and minimal fluid loss during operation. The valve's construction includes Sun's floating style design which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The CXCDXDV check valve accommodates installation torques between 30 \u2013 35 lbf\u00b7ft (41 \u2013 47 Nm) and has a compact model weight of approximately 0.20 lbs (0.10 kg). It utilizes Viton seals for enhanced performance under various operating conditions. This model\u2019s robust design and precise engineering make it suitable for retrofitting existing hydraulic circuits where manifold drillings may be incorrect, thereby serving as a circuit saver by adapting seamlessly without the need for extensive modifications.
The Sun Hydraulics CXCDXDV (CXCDXDV) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This valve facilitates free flow from inlet port 2 to outlet port 1 while blocking the reverse flow, making it an essential component for circuits needing precise fluid control. The CXCDXDV model is housed in a T13A cavity and belongs to the Series 1 category of Sun Hydraulics' products. With a capacity of 15 gallons per minute (60 liters per minute) and the ability to withstand a maximum operating pressure of 5000 psi (350 bar), this valve is crafted to handle demanding applications. It features exceptionally low leakage rates, with maximum leakage confined to less than one drop per minute (0.07 cc/min), ensuring efficiency and minimal fluid loss during operation. The valve's construction includes Sun's floating style design which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. The CXCDXDV check valve accommodates installation torques between 30 \u2013 35 lbf\u00b7ft (41 \u2013 47 Nm) and has a compact model weight of approximately 0.20 lbs (0.10 kg). It utilizes Viton seals for enhanced performance under various operating conditions. This model\u2019s robust design and precise engineering make it suitable for retrofitting existing hydraulic circuits where manifold drillings may be incorrect, thereby serving as a circuit saver by adapting seamlessly without the need for extensive modifications.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-13A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-010-006 |
