SUN HYDRAULICS
CXCDXFV
$34.26 USD
- SUN HYDRAULICS
- Material:CXCDXFV
- Model:CXCD-XFV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXCDXFV (CXCDXFV) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This model utilizes a freeflow, side-to-nose configuration that allows fluid to flow freely from the inlet port 2 to the outlet port 1 while preventing backflow in the opposite direction. Engineered for efficiency, the CXCDXFV operates with an exceptional low leakage rate of less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and maintaining system integrity. This valve is built to accommodate up to 5000 psi (350 bar) at both ports and has a maximum capacity of 15 gpm (60 L/min). The robust design incorporates Sun\u2019s floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This feature enhances the valve's durability and reliability in demanding operational conditions. The CXCDXFV is housed in a T13A cavity and belongs to Series 1 of Sun Hydraulics\u2019 product line. It requires an installation torque between 30-35 lbf ft (41-47 Nm) and features a hex size of 7/8 in. (22.2 mm). Weighing just 0.20 lb (0.10 kg), this compact valve is ideal for integration into existing circuits where manifold drillings are incorrect, acting as a circuit saver by adapting efficiently without extensive modifications. Additional specifications include the use of Viton seals for enhanced chemical resistance and operational longevity, making it suitable for various hydraulic applications where high pressure and low leakage are critical requirements.
The Sun Hydraulics CXCDXFV (CXCDXFV) is a high-performance check valve designed for hydraulic applications requiring reliable, one-way flow control. This model utilizes a freeflow, side-to-nose configuration that allows fluid to flow freely from the inlet port 2 to the outlet port 1 while preventing backflow in the opposite direction. Engineered for efficiency, the CXCDXFV operates with an exceptional low leakage rate of less than one drop per minute (0.07 cc/min), ensuring minimal fluid loss and maintaining system integrity. This valve is built to accommodate up to 5000 psi (350 bar) at both ports and has a maximum capacity of 15 gpm (60 L/min). The robust design incorporates Sun\u2019s floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This feature enhances the valve's durability and reliability in demanding operational conditions. The CXCDXFV is housed in a T13A cavity and belongs to Series 1 of Sun Hydraulics\u2019 product line. It requires an installation torque between 30-35 lbf ft (41-47 Nm) and features a hex size of 7/8 in. (22.2 mm). Weighing just 0.20 lb (0.10 kg), this compact valve is ideal for integration into existing circuits where manifold drillings are incorrect, acting as a circuit saver by adapting efficiently without extensive modifications. Additional specifications include the use of Viton seals for enhanced chemical resistance and operational longevity, making it suitable for various hydraulic applications where high pressure and low leakage are critical requirements.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-13A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-010-006 |
