SUN HYDRAULICS
CXCDXZV
$36.24 USD
- SUN HYDRAULICS
- Material:CXCDXZV
- Model:CXCD-XZV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXCDXZV (CXCDXZV) is a high-performance hydraulic check valve designed for efficient flow control in hydraulic systems. This model, part of the T13A cavity series, is particularly suited for applications requiring reliable one-way flow with minimal leakage. It allows free flow from inlet port 2 to outlet port 1 while blocking reverse flow, ensuring operational integrity and preventing potential damage to the hydraulic circuit. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity of up to 15 gallons per minute (60 L/min), the CXCDXZV valve accommodates substantial hydraulic loads while maintaining stability and responsiveness. The valve's construction features Sun Hydraulics' floating style design which minimizes internal part binding and wear, even under conditions of excessive installation torque or cavity/cartridge machining discrepancies. This model is engineered to offer exceptionally low leakage rates, less than 1 drop per minute (0.07 cc/min), which contributes significantly to system efficiency by reducing fluid loss and maintaining pressure consistency. The valve's robust design includes a hex size of 7/8 inches (22.2 mm) and requires an installation torque between 30 - 35 lbf ft (41 - 47 Nm), making it easy to install while ensuring secure fitting. Weighing just .20 lb (0.10 kg), the CXCDXZV is lightweight yet durable, crafted to withstand rigorous use in varied hydraulic applications without compromising performance. It also supports Viton seals through its seal kit/cartridge configuration, enhancing its suitability for high-temperature environments and various fluid types. This check valve is an ideal solution for circuit correction in existing systems or as a dependable component in new hydraulic installations.
The Sun Hydraulics CXCDXZV (CXCDXZV) is a high-performance hydraulic check valve designed for efficient flow control in hydraulic systems. This model, part of the T13A cavity series, is particularly suited for applications requiring reliable one-way flow with minimal leakage. It allows free flow from inlet port 2 to outlet port 1 while blocking reverse flow, ensuring operational integrity and preventing potential damage to the hydraulic circuit. With a maximum operating pressure of 5000 psi (350 bar) and a flow capacity of up to 15 gallons per minute (60 L/min), the CXCDXZV valve accommodates substantial hydraulic loads while maintaining stability and responsiveness. The valve's construction features Sun Hydraulics' floating style design which minimizes internal part binding and wear, even under conditions of excessive installation torque or cavity/cartridge machining discrepancies. This model is engineered to offer exceptionally low leakage rates, less than 1 drop per minute (0.07 cc/min), which contributes significantly to system efficiency by reducing fluid loss and maintaining pressure consistency. The valve's robust design includes a hex size of 7/8 inches (22.2 mm) and requires an installation torque between 30 - 35 lbf ft (41 - 47 Nm), making it easy to install while ensuring secure fitting. Weighing just .20 lb (0.10 kg), the CXCDXZV is lightweight yet durable, crafted to withstand rigorous use in varied hydraulic applications without compromising performance. It also supports Viton seals through its seal kit/cartridge configuration, enhancing its suitability for high-temperature environments and various fluid types. This check valve is an ideal solution for circuit correction in existing systems or as a dependable component in new hydraulic installations.
Free-flow, side-to-nose check valves are on/off circuit components that allow free flow from the inlet (port 2) to the outlet (port 1) and block flow in the opposite direction.
- Two-port check valves share the same cavity for a given frame size, however, pay close attention as flow paths may be in opposite directions.
- These check valves are considered circuit savers for existing circuits where manifold drillings are incorrect. The capacity of side-to-nose (port 2 to port 1) 2-port check valves is approximately 30% less than preferred models with a nose-to-side (port 1 to port 2) flow path.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-13A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .20 lb0,10 kg |
| Seal kit - Cartridge | Viton: 990-010-006 |
