SUN HYDRAULICS
CXDBXFN
$36.84 USD
- SUN HYDRAULICS
- Material:CXDBXFN
- Model:CXDB-XFN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXDBXFN (CXDBXFN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model, part of the T10A cavity series, is engineered to facilitate free flow from inlet port 1 to outlet port 2 while effectively blocking flow in the reverse direction. It boasts an impressive capacity of up to 20 gpm (80 L/min) and can handle a maximum pressure of 5000 psi (350 bar) at both ports. Featuring Sun Hydraulics' innovative floating style construction, the CXDBXFN minimizes the risk of internal parts binding, a common issue that can arise from over-torquing during installation or due to variations in cavity/cartridge machining. This design enhancement ensures consistent and reliable valve operation even under demanding conditions. The valve is equipped with a hex size of 7/8 inches (22.2 mm) and requires an installation torque between 30 - 35 lbf\u00b7ft (41 - 47 Nm). Additionally, the CXDBXFN uses Viton seals for enhanced durability and resistance against high temperatures and chemicals, making it suitable for a variety of fluid power applications where minimal leakage is crucial. The valve's superior sealing capability is evidenced by its extremely low leakage rate of less than one drop per minute (0.07 cc/min), ensuring efficient system performance with minimal fluid loss.
The Sun Hydraulics CXDBXFN (CXDBXFN) is a high-performance check valve designed for hydraulic systems requiring reliable, one-way flow control. This model, part of the T10A cavity series, is engineered to facilitate free flow from inlet port 1 to outlet port 2 while effectively blocking flow in the reverse direction. It boasts an impressive capacity of up to 20 gpm (80 L/min) and can handle a maximum pressure of 5000 psi (350 bar) at both ports. Featuring Sun Hydraulics' innovative floating style construction, the CXDBXFN minimizes the risk of internal parts binding, a common issue that can arise from over-torquing during installation or due to variations in cavity/cartridge machining. This design enhancement ensures consistent and reliable valve operation even under demanding conditions. The valve is equipped with a hex size of 7/8 inches (22.2 mm) and requires an installation torque between 30 - 35 lbf\u00b7ft (41 - 47 Nm). Additionally, the CXDBXFN uses Viton seals for enhanced durability and resistance against high temperatures and chemicals, making it suitable for a variety of fluid power applications where minimal leakage is crucial. The valve's superior sealing capability is evidenced by its extremely low leakage rate of less than one drop per minute (0.07 cc/min), ensuring efficient system performance with minimal fluid loss.
Free-flow, nose-to-side check valves are on/off circuit components that allow free flow from the inlet (port 1) to the outlet (port 2) and block flow in the opposite direction.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Will accept 5000 psi (350 bar) at ports 1 and 2.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-10A |
| Series | 1 |
| Capacity | 20 gpm80 L/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Seal kit - Cartridge | Viton: 990-010-006 |
