SUN HYDRAULICS
CXDBXFV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXDBXFV (CXDBXFV) is an advanced hydraulic check valve designed for high-pressure applications, offering a robust solution for controlling fluid flow in hydraulic systems. This valve allows free flow from the inlet port 1 to the outlet port 2 while effectively blocking flow in the reverse direction, ensuring reliable operation and system safety. The CXDBXFV model is characterized by its extremely low leakage rate, with a maximum leakage of less than 1 drop per minute (0.07 cc/min), making it highly efficient and minimizing fluid loss. Constructed to handle pressures up to 5000 psi (350 bar) at both ports, this valve is suitable for demanding environments. It features a T10A cavity and belongs to Series 1, with a flow capacity of up to 20 gpm (80 L/min). The check valve's dimensions include a hex size of 7/8 in. (22.2 mm) and an installation torque range between 30 \u2013 35 lbf\u00b7ft (41 \u2013 47 Nm). Additionally, it incorporates Sun's floating style construction which reduces the risk of internal parts binding due to excessive installation torque or cavity/cartridge machining variations. Equipped with Viton seals as indicated by the seal kit/cartridge specification (990010006), the CXDBXFV ensures enhanced chemical resistance and performance reliability under various operating conditions. This model is particularly suitable for applications where unidirectional flow and leak tightness are critical, providing a high-performance solution in hydraulic circuits where space and efficiency are valued.
