SUN HYDRAULICS
CXDCXAN
$33.86 USD
- SUN HYDRAULICS
- Material:CXDCXAN
- Model:CXDC-XAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics CXDCXAN (CXDCXAN) is a versatile hydraulic check valve specifically designed for high-efficiency fluid control in hydraulic systems. This model functions as a standard 2-port check valve within a 3-port cavity, with the third port blocked off, making it ideal for applications where a traditional check valve is needed but only a three-port cavity is available. The CXDCXAN offers an extremely low leakage rate, less than 1 drop per minute (0.07 cc/min), ensuring minimal fluid loss and increased system efficiency. Constructed using Sun\u2019s floating style design, the CXDCXAN minimizes the risk of internal parts binding which can occur due to over-torquing during installation or variations in cavity/cartridge machining. This feature enhances the durability and reliability of the valve under various operational conditions. The valve fits into a T11A cavity and is part of Sun Hydraulics' Series 1, designed to handle a flow capacity up to 20 gpm (80 L/min) and withstand maximum operating pressures up to 5000 psi (350 bar). Key specifications include a hex size of 7/8 in. (22.2 mm) and an installation torque requirement between 30 \u2013 35 lbf\u00b7ft (41 \u2013 47 Nm). The CXDCXAN uses Viton seals for enhanced performance under varying temperature and chemical conditions, making it suitable for diverse hydraulic applications that require reliable backflow prevention with minimal fluid leakage.
The Sun Hydraulics CXDCXAN (CXDCXAN) is a versatile hydraulic check valve specifically designed for high-efficiency fluid control in hydraulic systems. This model functions as a standard 2-port check valve within a 3-port cavity, with the third port blocked off, making it ideal for applications where a traditional check valve is needed but only a three-port cavity is available. The CXDCXAN offers an extremely low leakage rate, less than 1 drop per minute (0.07 cc/min), ensuring minimal fluid loss and increased system efficiency. Constructed using Sun\u2019s floating style design, the CXDCXAN minimizes the risk of internal parts binding which can occur due to over-torquing during installation or variations in cavity/cartridge machining. This feature enhances the durability and reliability of the valve under various operational conditions. The valve fits into a T11A cavity and is part of Sun Hydraulics' Series 1, designed to handle a flow capacity up to 20 gpm (80 L/min) and withstand maximum operating pressures up to 5000 psi (350 bar). Key specifications include a hex size of 7/8 in. (22.2 mm) and an installation torque requirement between 30 \u2013 35 lbf\u00b7ft (41 \u2013 47 Nm). The CXDCXAN uses Viton seals for enhanced performance under varying temperature and chemical conditions, making it suitable for diverse hydraulic applications that require reliable backflow prevention with minimal fluid leakage.
Free-flow, nose-to-side cheater check valves function as a standard 2-port check valve in a 3-port cavity with port 3 of the cartridge blocked off. These valves are useful in circuits where a check valve is required in an existing three port cavity.
- Check valves offer extremely low leakage rates with a maximum leakage of less than 1 drop per minute (0,07 cc/min).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 20 gpm80 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 drops/min.0,07 cc/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Seal kit - Cartridge | Viton: 990-011-006 |
